400W High Power Waterproof Outdoor Prisons Jails Signal Jammer Supplier With 1 Year Warranty!
Frequency Can Be Customized!
Description:
This jammer is a waterproof model. Using high quality waterproof case, ensure stability of the equipment ,even work in bad weather conditions.
Equipped with special high gain directional planar antenna or fiberglass omni-directional whip antenna, the jammer can effective block CDMA/GSM/DCS /3G/ LTE/WIMAX / Wifi /GPS.
Use the overseas advanced chip and technology . With independent modular design, it keeps high operation efficiency, and avoid mutual interference.
100 watts per band, total RF power 400 watts, also with power adjustable switches to
control the radius range. It is suitable for prisons, detention houses, military bases, large oil fields and all other outdoor places where need the signal to block.
Specifications A:
Output interface | Shield band of frequency | RF output power | Output power/channel |
CDMA 800 | 851 - 894 MHz | 50dBm | 27dBm/30KHz(min) |
GSM 900 | 925 -960MHz | 50dBm | 27dBm/30KHz(min) |
DCS/PCS | 1805 - 1990 MHz | 50dBm | 24dBm/30KHz(min) |
3G 2100 | 2110 - 2170 MHz | 50dBm | 24dBm/30KHz(min) |
Specifications B:
Output interface | Shield band of frequency | RF output power | Output power/channel |
CDMA 800 | 851 - 894 MHz | 50dBm | 27dBm/30KHz(min) |
PCS | 1930 - 1990 MHz | 50dBm | 24dBm/30KHz(min) |
3G 2100 | 2110 - 2170 MHz | 50dBm | 24dBm/30KHz(min) |
Wimax | 2300-2390MHz | 50dBm | 24dBm/30KHz(min) |
Specifications C:
Output interface | Shield band of frequency | RF output power | Output power/channel |
GSM 900 | 925 -960MHz | 50dBm | 27dBm/30KHz(min) |
DCS 1800 | 1805 - 1880 MHz | 50dBm | 24dBm/30KHz(min) |
3G 2100 | 2110 - 2170 MHz | 50dBm | 24dBm/30KHz(min) |
4G 2600 | 2620-2690 MHZ | 50dBm | 24dBm/30KHz(min) |
Specifications D:
Output interface | Shield band of frequency | RF output power | Output power/channel |
GSM 900 | 925 -960MHz | 50dBm | 27dBm/30KHz(min) |
DCS 1800 | 1805 - 1880 MHz | 50dBm | 24dBm/30KHz(min) |
3G 2100 | 2110 - 2170 MHz | 50dBm | 24dBm/30KHz(min) |
Wifi | 2400-2500 MHZ | 50dBm | 24dBm/30KHz(min) |
Competitive Advantage:
1. Using high quality waterproof case, ensure stability of the equipment even work in bad weather
conditions.
2.with good cooling system, can operate for long time.
3.Using digital interference technology, overall effective suppression of target spectrum.
4.independent module design. Each module can separate switch,disassemble. So it is convenient for
maintenance and update.
5. Perfect Alarm System, fully protected circuit in case of disconnection of antennas.
Applications:
1. prison
2. Military camp
3. detention houses
4. oil fields.
5. Museums
6. Drug Enforcement
7. Secret Services
