Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Stable Performance Concrete Weigh Batcher / Way Batcher Machine PLD1600
Specifications
Brand Name :
Jianxin
Model Number :
PLD1600
Certification :
ISO CE
Place of Origin :
China
MOQ :
one set
Price :
$2,800.00 - $9,800.00 / Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
8-10 days
Packaging Details :
China Standdard package
Weigh hopper capacity :
1600L
Hopper capacity :
4×5m3
automatic weighing accuracy :
±2%
Maximum capacity :
3000kg
PLD1600 Concrete batcher filling height :
2900mm
PLD1600 Concrete batcher power :
5×3KW
Description

Stable and High Quality Small Concrete Batcher PLD1600

PLD1600 Concrete batcher introduction

1. Zhengzhou new mechanical batching machine top panel can be reduced, and can greatly reduce labor intensity of the feeding part, increasing the ease of construction. PLD series of concrete batching machine is using loaders or gravel material dosing device on belt conveyors, to match three or more items, and various types of supporting the use of blenders and other measurement devices can be combined into a mix of fully automatic or semi-automatic stations.
2.The PLD series of concrete batching machine strictly in accordance with the standards of design, simple, one-button operation, this series of concrete batching machine with the corresponding concrete mixer combinations can be different form combined with the specifications of the mixing plant, ideal for on-site production of high quality concrete.

Advantages of small concrete batcher pld1600
1.Microcomputer control-computer control can be set according to the user a variety of material of concrete ratio Automatic batching.
2.Batching machine has a capacity of 800, 1200, 1600, the material at a mixer to enhance fighting directly, or by a belt conveyor.
3. Batching weighing system using the weight of the machine controller and sensors, quantifying the material, ingredients and control, and automatically modify the drop.
4.The new weighing Batcher includes separate weighing and additive weighing, which can weigh 4 bone, short measurement time, and high efficiency.

Technical Parameters

Model PLD1600
Weigh hopper capacity(L) 1600L
Storage hopper capacity 4*5m³
Theoretical productivity ≤75m³/h
Batching accuracy ±2%
Maximum weighing value(kg) 3000
Number of ingredients available 2-5种
Feeding height(mm) 2900
Feed belt speed(m/s) 1
power 5*3KW
The capacity of the whole machine(kg) 5600
Overall dimensions (length * width * height)(mm) 12000*2200* 3260
