150T Concrete Cement Silo 15840mm Total Height For Concrete Mixing Stations
150T Concrete Cement Silo 15840mm Total Height For Concrete Mixing Stations
Specifications
Brand Name :
TORUI
Model Number :
150T
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Supply Ability :
50 set/month
Delivery Time :
20-25 Work Days
Packaging Details :
Custom required
Model :
150T
Tank Diameter :
φ3200mm
Straight SectionHeight :
13500mm
Total Height :
15840mm
Description

150T Concrete Bunker

Introduction to Cement Silo

The cement silo, also known as the cement bunker, is a sealed container used for storing bulk cement. It plays an important role in material storage in the fields of construction engineering, concrete mixing stations, cement plants, and other areas.

Structural Components

  1. Silo body: welded with steel plates, it has sufficient strength and stability to bear the weight of the cement and the internal pressure. The shape of the silo body is usually cylindrical or conical.
  2. Support legs: Used to support the weight of the entire cement silo to ensure its stability and safety. The number and form of the support legs depend on the size and design requirements of the cement silo.
  3. Feed pipe: Used to convey the bulk cement into the cement silo and is usually connected to conveying equipment such as screw conveyors and pneumatic conveying equipment.
  4. Discharge pipe: Installed at the bottom of the cement silo, the stored cement is conveyed to the required place, such as a concrete mixer, by controlling the valve.
  5. Dust removal system: In order to prevent dust pollution to the environment during the feeding and discharging processes, the cement silo is usually equipped with dust removal equipment such as bag dust collectors or pulse dust collectors.
  6. Material level meter: Used to monitor the storage amount of cement in the cement silo so as to replenish or control the discharge amount in time.
  7. Safety accessories: Include safety valves, pressure sensors, lightning protection devices, etc., to ensure the safety of the cement silo during use.


Spec		 Tank Diameter(mm) straight section Height(mm) Total Height(mm)
50T φ2800 5500 7555
φ3000 4500 6700
60T φ2800 6750 8805
φ3000 6000 8200
80T φ2800 9000 11055
φ3000 7500 9700
100T φ2800 10500 12555
φ3000 9750 11950
150T φ3200 13500 15840
