PE Series Stone Crushing Line Jaw Stone Crusher With 5-20t/H Capacity
PE Series Stone Crushing Line Jaw Stone Crusher With 5-20t/H Capacity
Specifications
Brand Name :
TORUI
Model Number :
PE-250x400
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Supply Ability :
30 set/month
Delivery Time :
30-35 Work Days
Packaging Details :
Custom required
Model :
PE-250*400
Feeding opening size :
250*400mm
Max feeding size :
210mm
Discharge opening size :
20-60mm
Capacity :
5-20t/h
Motor power :
15kw
Weight :
2.8t
Description

PY Series Spring Cone Crusher

Brief Introduction


Jaw Crusher is ideally suitable for primary and secondary crushing for material with compression strength less than 320MPA.
Jaw Crusher has the features of high crushing ratio,larger capacity,even final product size,simple structure,reliable performance,convenient maintenance,lower operation cost,etc.It is widely used in mining,metallurgy,construction, highway,railroad and water conservancy industry,etc.

Features and Advantages


1.High crushing ratio. even final product size,
2.Adjusting wedge makes discharging opening have wideadjustable range.reliable and convenient, thus it is capable to meetvarious requirements of customers:
3.Lubrication system is safe and reliable, easily to replace the partsand small maintenance workload;
4.Simple structure, reliable performance, low maintenance andoperating cost;
5.Little dust and low noise.

Model Feeding opening size
(mm)		 Max feeding size
(mm)		 Discharging opening size
(mm)		 Capacity
(t/h)		 Motor power
(kw)		 Weight
(t)		 Overall dimension (LxWxH) (mm)
PE-250x400 250x400 210 20-60 5-20 15 2.8 1180x1087x1245
PE-400x600 400x600 340 40-100 16-60 30 6.65 1797x1716x1581
PE-500x750 500x750 425 50-100 40-110 55 11.73 2119x1918x2046
PE-600x900 600x900 500 65-180 80-180 55-75 16.13 2309x2028x2368
PE-750X1060 750x1060 630 80-180 110-320 90-110 30 2730x2472x2840
PE-870X1060 870x1060 750 1 70-270 180-360 90-110 31.22 2990x2416x2893
PE-900X1200 900x1200 780 95-225 220-450 110-132 49 3362x2750x3260
PE-1000X1200 1000x1200 850 195-280 280-550 110-132 51 3823x2938x3285
PE-1200X1500 1200x1500 1020 150-300 400-800 160-220 100.9 4930x3334x4057
PEX-150x750 150x750 120 18-48 8-25 15 3.5 1252x1593x1025
PEX-250x750 250x750 210 20-50 13-35 30 4.96 1435x1832x1715
PEX-250X1000 250x1000 210 25-60 16-52 30-37 6.5 1706x1964x1380
PEX-250X1200 250x1200 210 25-60 20-61 37-45 8.8 1700x2132x1450
PEX-300X1300 300x1300 250 20-90 25-95 55-75 12.6 2026x2320x1723
