Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
VisionMaster
Model Number :
Passenger Counting System
Price :
Negotiable
MOQ :
1 Set/Sets
Certification :
CE FCC
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
2000 sets / month
Delivery Time :
3-5 work days for samples,15-30 work days for large orders
Packaging Details :
Neutral packing
Product name :
High Definition H.264 Automatic People Counter With Graphical User Interface
Storage :
sd card slot x 2 (128GB/sd card)
Video interface :
Aviation Connector
Image Resolution :
4x720PAHD or 4x960H/D1/HD1/CIF+1XIPC
Operation Menu :
Graphical User interface(OSD menu)
Video input :
4 Channels
Type :
AHD Mobile DVR
Video Compression :
H. 264
Description

High Definition H.264 Automatic People Counter With Graphical User Interface

The device supports 360 ° installation, please install the device in the suitable location according to the counter’s size of hole site. (Suggest installing horizontally to ensure that in extreme conditions the equipment can also work properly, taking into account the host of waterproof, moisture, lightning protection, to prevent car washing, moisture and other circumstances lead to car boot burned motherboard).

Connect the 6-pin white plug to the 6-pin power input port on the rear panel of the MDVR, while the red and black cables are directly connected to the battery of the vehicle, i.e. positive terminal and negative terminal respectively, or to the main power. The yellow cable is connected to ACC, the vehicle control circuit switch (used to start the vehicle motor). The unit will be enabled automatically when the car key is enabled and disabled when the key is disabled.

When the device is not installed in a vehicle (such as monitoring systems in bus station, logistic transfer) or under test, you can use a switching power above DC12V-5A to supply the mainframe. In this case, twist the red and yellow cables as a cable to connect it to the positive terminal, while the black one is connected to the negative terminal separately.

High Definition H.264 Automatic People Counter With Graphical User Interface

High Definition H.264 Automatic People Counter With Graphical User Interface

1.1 Electrical Specifications

Power supply +8～+36V 8V～36V, Check the supply voltage of the vehicle battery before use; if it is supplied with more than 36V for a prolonged period, the device may be damaged.
Power output 12V 12V(+/-0.2V), max. current: 3A
ACC detection ≤4V Power off
≥6V Power on
Video input impedance 75Ω Each video input impedance: 75Ω
Video output voltage 2Vp-p 2VP-P CVBS output analog signal which should be adapted by 75Ω of input impedance from the display unit.
I/O interface 1V or below Low level alarm
5V or above High level alarm
Working temperature -25℃ ~ 75℃ In a well-ventilated place
Size 170(W)mmx50(H)mmx142(L)mm
