720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
Specifications
Certification :
CE,FCC
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
VisionMaster
Model Number :
VM-1504-HD
Price :
Negotiable
MOQ :
1 Set/Sets
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
2000 sets / month
Delivery Time :
3-5 work days for samples,15-30 work days for large orders
Packaging Details :
Neutral packing
Warranty :
1 Years, 12 months
Product Name :
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
Compression :
H.264 4channel
Dimension :
L233*W300*H45 mm
Range of use :
car, bus, truck, ship
Display Quality :
TV: D1 VGA: High definition
Voltage :
DC8~36V
Storage :
2*128GB SD card
Description

720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language

Product descripiton

VM-1504-HD Series is Mega Pixels HD Multi-Functional Mobile DVR .H.264 compression mode ,supports 4ch realtime 720P Mega Pixels AHD input and Analog satandard defition camera input; Exclusive pre-allocate DVR Special File system Technology,Solving repeatedly wipe cause file fragmentation, solving SD card file system collapse data loss and thus can not find SD card and file garbled,ensuring the integrity of the data .

Common Questions and Answers (QA) for MDVR

Q:When Device issue appear,you are confused on how to solve it.

A:Check Device Item No & Firmware Version,sent back to us with detail description of issue.Our Technical Team will handle it.

More detail you described,easier for us to solve it quickly.

Q:Video Output Lost

A:1.Check situation of DVR:Device Input Power;Power Cable Connection;GND Connect to battery;fuse;RED & Yellow Cable of Power must connect together;

2.Check the Screen Power or Check if the Screen change to related AV Channel;

3.Check the connection of Video Output & Screen Cable;

720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language

Main Features

1. Power failure protection.

2. Wide voltage (8-36V).
3. OTA function support. (Upgrating DVR software automatically, better after-sales service for you.
4. A SMS can get DVR situation feedback from DVR

5. Industrial level design. (More professional and better quality.)
6. Modular design. (To prevent a module error while affecting the entire product.)
7. Encrypt video format. (To prevent data loss)
8. Current and voltage over protection.
9. Wide working temperature. (-25°C- +75°C).
10. Data redundancy technology. (To prevent data loss)
11. Excellent vibration protection.

720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language

Item Parameter
OS Linux
Language Chinese/English/Customized
Video Compression H.264
OSD Overlays information such as date time and vehicle ID
Graphical User Interface Setup system parameters with the remote control.
Video Record System Video Input 4CH 720P AHD input,aviation connector, 1.0Vp-p, 75Ω
Preview Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview
Resolution 720P/D1/HD1/CIF, MAX:4 channels of 720P and 4 channels of D1
Video Quality 1-4 levels, 1 is the highest level.
Video Standard P/N
Audio Audio Input 4CH ,Aviation Plug
Audio Output 1CH,Aviation Plug
Alarm Input 3Ch Alarm Input, kinds of alarm linkage support
Alarm Output 1CH Alarm Output
G-Sensor Support G-sensor
Storage SD Dual SD Card,each max 128GB SD Card loop recording
Video Playback Video Search Search By Record Time/Record Type etc
Playback Max support 4CH Replay /Stop/Fast/Slow at same time
Support forward and backward playat the speed of: x 2,x4,x8,x16.
Voltage & Power Power Management Wide Voltage.Support Timed/Delay off
Voltage Input DC:+10V ~ +36V
Working Environment Temperature -20℃ to +70℃
Humidity 20% to 80%
Security Password User/Admin 2 Level Different Password
others Size 112(W) x36(H) x138(D) mm
Net Weight 360g

Packaging
720P Truck / Ship 4G Mobile DVR With Sim Card Four Channels Customized Language
