8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars
8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars
8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars
8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars
Specifications
Brand Name :
Visionmaster
Model Number :
VM-3608-HD
Certification :
CE FCC
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
2000 sets / month
Delivery Time :
3-5 work days for samples,15-30 work days for large orders
Packaging Details :
Neutral packing
Resolution :
8x1080p/960p/720 ahd /960H/D1/HD1/CIF+1x IPC
Storage :
2TB+128GB
Video&Audio inputs :
8ch analogue +1 ch IPC
Type :
MDVR
Application :
vehicles school buses cars financial convoy cars fuel tankers.
warranty :
one year
Product name :
best mdvr 2tb 128gb 8channels video audio ahd 1080p for school bus
RS485 &RS232 :
Yes
USB :
Yes
RJ45 :
Yes
Description

8 Channel 2TB HDD Vehicle Mobile DVR Recorder Vehicles School Buses Cars

Vehicle Mobile DVR Specification

Item Parameter
OS Linux
Language Chinese/English/Others (can be customized)
Video Compression H.264 Compression Mode
OSD Overlays information such as date time and vehicle ID
GUI Graphical User Interface Can connect to external LED screen. Setup system parameters with the remote control.
Video Record System Video Input 8CH 720P AHD/8CH 1080P AHD input ,aviation connector.
Video Output 1CH CVBS+ VGA output for optional, 1.0Vp-p, 75Ω,Aviation
Preview Support 1 / 2 / 4 / 5 / 6 / 8 / 9 channels preview.,Support Manual/Alarm Trigger full screen preview
Resolution Support 1080P/720P/D1/CIF, MAX:8 channels 1080P
Video Quality 0-7 levels, 0 is the highest level, 7 is the lowest level.
Video Standard

PAL: 100f/s , CCIR625 line,50field;

NTSC: 120f/s, CCIR525 line,60field;

CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional;

HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional;

D1: 800Kbps ~ 3Mbps, multi levels video quality optional;

720P : 1Mbps~4Mbps, multi levels video quality optional;

1080P: multi levels video quality optional;
Record Mode The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported.
Audio Audio Input 9CH ,Aviation Plug
Audio Output 2CH,Front port is earphone port ,rear port connects to BNC connector.
Compression G.726 compression, 8KB/s speed
Alarm Input 16CH IO Alarm Input, 2CH AD input, pulse speed input; Support alarm linkage function
Alarm Output 4CH Relay Alarm Output, Support the linkage acousto-optic alarm, cut off fuel oil/power,etc
Communication Interface 2CH RS232, support extension device, such as POS machine, Oil Feul sensor, LED advertising screen , etc.
2CH 485 interface, can connect PTZ,etc.
2CH CAN interface.
Wireless transfer Support Built-in 3G network, WCDMA,CDMA2000,TD-SCDMA compatible with GPRS,EDGE; Support Built-in 4G network, TTD-LTE, FDD-LTE
Position Support Built GPS/BD Module,can make playback analysis of vehicle routing
G-Sensor Support G-sensor
Video Storage Storage 2.5’’ HDD+ SD Card,each max 2TB HDD + 128GB SD Card mirror recording to protect data from loss
Upgrade Support USB flash disk updating,SD card upgrade , OTA remote upgrade automatically
File Format .264
File System Special Car system File System
USB Front panel supports USB port, support USB flash disk upgrade to backup; hard disk box USB port, can back up video data
Video Playback Video Search Search video by Record Time/Record Type etc
Playback Max support 8CH Replay /Stop/Fast Forward/Fast Reverse at same time
Support x 2,x4,x8,x16. fast forward or fast backward play
Print Mode thermosensitive
Print Speed 30mm／second
Print width 57.5±0.5mm
Resolution 8 points per millimeter
Print Paper width ≤57.5±0.5mm
Safety Management User/Admin 2 Levels Different Passwords , support screen lock
Voltage & Power Consumption Power Management Adaptive wide power input, support Wide Voltage, Over-load,Over-voltage,Short Circuit,Reverse Protection..Support Time Setting/Delay power off
Voltage Input DC:+8V ~ +36V
Voltage Output +12V@2.5A,+5V@2.5A
Power-off Protection UPS Technology,All video information can be saved automatically when the power is cut off, and make sure that all the files can not be damaged.
Power Consumption Normal Working ＜10W
Working Environment Temperature -20℃ to +70℃
Humidity 20% to 80%
others Size 180mm*53mm*170mm
Net Weight ≤850g

8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars

8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars

Ø Real-time HD Video Recording, 1080P/720P/D1/HD1/CIF for Optional,Adjustable Frame Rate Quality.

Ø HIS Solution, H.264 Compression Mode, Many stream recording, support 8CH 2MP real-time video 2MP real-time video recording/Monitoring/Playback (4CH real-time 1080P AHD input/8CH 1080P 120 Fps AHD input / 8CH 720P real-time AHD input / 8CH D1 analog standard definition input), support million pixels HD video resolution.

Ø Professional Power Design for all kinds of Vehicles, 8-36V DC; Wide Voltage, Over-load,Over-voltage,Short Circuit,Reverse Protection,Suitable for all kinds of vehicles.

Ø Support DC 12V output, it can offer power for cameras,mini monitor and some peripheral device.

Ø Hard Disk + SD card Data record storage (maximum support 2TB 2.5’ hard disk and 128GB SD card ) It can be completely resist car Vibration,Dust and others cause data corruption;

Ø Watchdog Abnormal will trigger Restart Protection Function . It can better protect Device and Video.

Ø Exclusive Pre-Allocate DVR Special File System Technology, Solving repeatedly wipe cause file fragmentation, and ensure the integrity of the data.

Ø By accidents power-off protection function.Unique UPS Technology ensures the integrality of record when power failure occurs,even can for 8-11s.

Ø Flame out Time-lapse Video Recording Function ( Highest support long delay time 24 hours.)

Ø Auto Recording,Time Recording,Alarming Recording Modes for Different Request.

8 Channel Vehicle Mobile DVR Recorder 2TB HDD USB RJ45 For School Buses Cars

Company Profile

Visionmaster Industrial Co., Ltd. is a leading video surveillance solution provider with global perspective.

We have a professional team of more than 100 people, including more than 30 engineers.
Through our dedication to customer-centric innovation and strong partnerships, we are creating maximum value for international distributors, installers by committing end user competitive mobile surveillance and DVR solutions.
Our solutions have been deployed worldwide among various applications including public transportation, school bus, law enforcement, private fleet, logistics management, railway and metro, mobile media operation, etc. We continue to enjoy rapid and steady growth and would like to invite you to be part of our global success.
