High Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFI
High Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFI
High Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFI
High Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFI
Specifications
Brand Name :
VisionMaster
Model Number :
VM-1504-HD
Certification :
CE,FCC
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
2000 sets / month
Delivery Time :
3-5 work days for samples,15-30 work days for large orders
Packaging Details :
Neutral packing
Compression :
H.264 4channel
Weight :
1KG
Dimension :
L233*W300*H45 mm
Range of use :
car, bus, truck, ship
Display Quality :
TV: D1 VGA: High definition
Voltage :
8~36V
Resolution :
720P
Video output :
VGA & A/V
Description

4CH 720P AHD 4G Mobile DVR H264 Video 128GB SD Card With GPS WIFI

Product Feature

◆ HIS Solution,H.264 Compression, Dual Stream,4CH Video and 4CH Audio input;720P AHD Camera & Normal Analog Camera input compatibility;

◆ High quality real time recording, 720P/CIF/HD1/D1 Optional, quality adjustable;

◆ Professional Car Power Design,10-36V wide voltage,Provide reverse voltage/overload/short circuit protection, to meet kinds of car application;

◆ Support 12VDC/2.5Amp output voltage,power supply for Camera/Screen etc;
◆ Dual SD Card Support, each max 128GB,,protect DVR from shock & Dust damage;
◆ Watchdog abnormal restart function,protect SD Card and Record;

◆ Exclusive File System protect data completeness,prevent SD Card fragment;

◆ ACC Delay off,can set 24 hours;

◆ Auto Record/Manual Record/Alarm Record etc working mode to meet different requirements;
◆ Show Car status/Plate/Driving Route/Low Speed/Over Speed information for convenient management;
◆ Support GPS/BD G-sensor Optional;
◆ 3CH Alarm input(Door Open,Light,Turn direction,brake,reverse etc),can linkage kinds of alarm;

◆ 1CH Alarm Output;

◆ Support picture snap when alarm;
◆ Easily Smart GUI Interface, saving time in device setting;
◆ Stability Aviation plug, easily connecting and high shock proof;

◆ Be Customized according your request;

Item

Parameter

OS

Linux

Language

Chinese/English/Customized

Video Compression

H.264

OSD

Overlays information such as date time and vehicle ID

GUI

Graphical User Interface

Setup system parameters with the remote control.

Video Record System

Video Input

4CH 720P AHD input,aviation connector, 1.0Vp-p, 75Ω

Video Output

1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen

Preview

Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview

Resolution

720P/D1/HD1/CIF, MAX:4 channels of 720P and 4 channels of D1

Video Quality

1-4 levels, 1 is the highest level.

Video Standard

PAL: 100f/s , CCIR625 line,50field;

NTSC: 120f/s, CCIR525 line,60field;

CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional;

HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional;

D1: 800Kbps ~ 3Mbps, 8 level video quality optional;

720P: 4Mbps-6Mbps, multi level video quality optional

Record Mode

The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported.

Audio

Audio Input

4CH ,Aviation Plug

Audio Output

1CH,Aviation Plug

Compression

G.726 compression, 8KB/s speed

Alarm Input

3Ch Alarm Input, kinds of alarm linkage support

Alarm Output

1CH Alarm Output

Position

Support Built GPS/BD Module

G-Sensor

Support G-sensor

Storage

SD

Dual SD Card,each max 128GB SD Card loop recording

Upgrade

Support SD Card updating

File Format

.H264

File System

Special FAT32 File System

Video Playback

Video Search

Search By Record Time/Record Type etc

Playback

Max support 4CH Replay /Stop/Fast/Slow at same time

Support forward and backward play at the speed of: x 2,x4,x8,x16.

Voltage & Power

Power Management

Wide Voltage.Support Timed/Delay off

Voltage Input

DC:+10V ~ +36V

Voltage Output

+12V~2.5A,+5V~2.5A

Power Consumption

Normal Working

Working Environment

Temperature

-20°C to +70°C

Humidity

20% to 80%

Security

Password

User/Admin 2 Level Different Password

others

Size

112(W) x36(H) x138(D) mm

Net Weight

360g

High Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFIHigh Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFI

High Definition 4G Mobile DVR 4CH 720P AHD H264 Video 128GB SD Card With GPS WIFI
