160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
Specifications
Brand Name :
JESH
Model Number :
TB27J
Certification :
CE
Place of Origin :
China
MOQ :
1Unit
Price :
Negotiation
Payment Terms :
T/T, L/C, D/P, D/A, Western Union, MoneyGram
Supply Ability :
4000 Units per month
Delivery Time :
45 days
Packaging Details :
Regular factory packing
Color :
Green
Feature :
telescopic boom lift
Power :
Diesel engine
working height :
29m
horizontal outreach :
21.1m
platform capacity unrestricted :
360kgs
Description

160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform

Hunan JESH Heavy Industry Co.,Ltd is professional manufacturer of MEWPs (Mobile Elevating Work Platform) headquartered in Changsha,Hunan where is heavy machinery manufacturing base of China.JESH is specialized in research, production, sales and service of MEWPs.

JESH telescopic boom lift covers working height from 27m-43m, which is suitable for indoor or outdoor use on rough ground.

It is featured with advanced working height and outreach ability beyond the industry, which allow you to locate the working point accurately.

With outstanding gradeability and rough terrain performance, the working efficiency is greatly improved.

Technical Parameters

Model TB27J
Dimentions Metric
Max Working Height 29.0m
Max Platform Height 27.0m
Max Horizontal Outreach 21.1m
Extendable depth downward 1.6m
Platform Width 0.91m
Platform Length 2.44m
Height-Stowed 3.01m
Length-Stowed 14.4m
Transportation 11.9m
Width 2.48m
Wheelbase 3.0m
Ground Clearance-Center 0.39m
Productivity
Load capacity(unrestricted) 230kg
Load capacity(restricted) 360kg
Tail swing 1.574m
Min. Turning Radius(inside/outside) 3.7m/6.6m
Turntable Swing 360°continuous
Platform Rotation 160°
Jib rotation -60°~75°
Drive Speed(stowed) 5.4km/h
Drive Speed(extended) 1.1km/h
Control DC12V Proportional
Drive type 4 Wheels
Max. Grade ability 45%
Tire-solid foam filled( Dia.×Width) 1033×450mm
Power 　
Engine Kohler KDI 2504 TCR(55.4kW)
Fuel Diesel
Hydraulic Oil Tank Capacity 150L
Fuel Tank Capacity 120L

160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform

160° Telescopic Manlift Platform Capacity 360kgs On Ariel Work Platform
