This device is suitable for classroom, meeting room, library, movie theater and other places where need to keep quiet. Due to its small size and easy to hide, the device is popular with teachers and administrators. As the most popular portable mobile phone jammer, this product has a small size, easy to carry. Can block 8 frequencies, and have a very large jamming range. With a separate frequency control switch, you can select the frequency range that needs to be disturbed as needed.
Application Area:
Prisons, Recording Studios, Banks, Contract Tendering Rooms, Churches, Classrooms, Testing Facilities, Security Services, Military Units, Secret Services, News Conference Rooms, Libraries, Museums, Courts, Border Patrol and Drug Enforcement, Customs, etc.
Affected Frequency Ranges:
Output Interface | Output frequency |
CH1 | CDMA/GSM:851-960MHz |
CH2 | DCS/PCS:1805-1990MHz |
CH3 | 3G:2110-2170MHz |
CH4 | 4G LTE:725-770MHz |
CH5 | 4G Wimax:2345-2400MHz |
CH6 | WiFi:2400-2500MHz |
CH7 | VHF:135-174MHz |
CH8 | UHF:400-470MHz |
Total output power: | 18W |
Jamming range | up to 40m(15m for VHF/UHF) ), the jamming radius still depends on the strength of the signal in given area |
Power supply: | 50 to 60Hz, 100 to 240V AC |
With AC adapter | (AC100-240V-DC12V), |
Dimension: | 355 x 140 x 51mm |
Weight: | 4.0kg |
Antenna | External Omni-directional antennas all the TX frequency covered down link only |
Features:
Internal Cooling fan to make the jammer work more stably
Provide 360 degree jamming
Remote control available to ON/OFF the jammer
Output power can be adjustable
Each frequency channel can be controlled separately
Frequency ranges selectable
