Product Description:

Advantages

• Each unit can jam frequency bands simultaneously.
• Continuous operation even in hot climates with no time limits.
• Design for outdoor installation.
• Secure design to avoid sabotage.
• Antenna type options-Omni or directional antennas.
• Selection of antennas to provide more flexibility regarding jamming coverage.
• Additional option: wireless RC or Ethernet PC remote control.
• 100% Safe VSWR over protection for each modula.

• Designed to cut off wave only in the downlink band width, therefore, it doesn’t affect any interference to base station and repeater
• Remote Control
• IP68 Waterproof Housing Outdoor desig

Specifications:

· Isolating Signal Bandwidth:

CH1-CDMA/GSM: 850 to 960MHz
CH2-DCS : 1805-1880MHz
CH3-PCS : 1900-1980MHz
CH4-3G : 2110-2170MHz
CH5-4G LTE : 725-770MHz(US) or 790-826MHz(EU)
CH6-4G Wimax : 2300-2400MHz(US) or 2620-2690MHz(EU)
CH7-WiFi: 2400-2500MHz
CH8-GPSL1:1500-1600MHz
CH9-GPSL2:1220-1230MHz
CH10-GPSL3:1376-1386MHz
CH11-GPSL4:1376-1386MHz
CH12-GPSL5:1170-1180MHz
CH13-VHF 135-174MHz
CH14-UHF 400-470MHz

• Total Output Power: 500W
• Control: Each band can work independently
• Jamming range: 100-500m, (Signal strength <= -75dbm)
• Housing: Waterproof & shockproof design suitable indoor or outdoor use
• Dimension: 450x580x450mm
• Total System Weight: Approx 45 kg (with omnidirectional antennae.)
• Humidity: Up to 80%
• Operation Temperature: -20 ...+50 Centigrade degree
• Antenna Type: External (2-3dBi) omnidirectional (Standard)

Application area:

Meeting Room, Oil and Gas Storage Facilities and fields, Hospitals, Theatres, Recording Studios, Banks, Contract Tendering Rooms, Churches, Conference Rooms, Classrooms, Testing Facilities, Security Services, Military Units, Secret Services, News Conference Rooms, Libraries, Museums, Prisons, Courts, Border Patrol and Drug Enforcement, Customs, House, Small prison areas.
