Specifications
Brand Name :
wolvesteam
Model Number :
WT500106
Certification :
CE
Place of Origin :
China
MOQ :
1 piece
Price :
negotiated price
Payment Terms :
L/C, T/T
Supply Ability :
100pieces/month
Delivery Time :
25 days
Packaging Details :
Box , Size: 600×400×250mm Weight:24 Kg
Weight :
30 Kg
RF output power :
Up to 250W
Packing :
Box
Type :
Waterproof Prison Jammer
Advantage :
Keep for Upgrade Module Installation
Casing :
Aluminum - Alloy
Jamming range :
50-200 meters
Application Area :
Military Units, Prison, Police, Bomb Disposal
Description

Prison Cell Phone Jammers Customized Frequency With

Aluminum - Alloy Casing

Product Description:

This device is outdoor waterproof cell phone signal jammer with 4 to 5 bands for prison jamming / jail

jamming is a combination of advanced technology.

With the continuous development of communication standards, WT500106 is a high-tech prison jammer

product which is developed according to domestic and foreign channels of communication.

It can effectively shield (interference) in the radius of 50-200 meters all indoor and outdoor signals such as

2G / 3G / 4G mobile phone signal and intercom, remote bomb, WiFi signal, shielding eraser, SMS pen,

stealth headphones, watches cheating, glasses probe wireless signal, to prevent candidates cheat, protect

the venue quiet, and to prevent bomb attacks.

Advantages:

• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.

• Heat sink designing combing with the fans to make system in a cooling status.

• Special technology to prevent interference between each frequency band.

• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.

• Frequency bands and output power selectable.

• Each frequency band controlled by independent RF ON/OFF switches.

• Power of each frequency band can be adjustable independently.

• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.

• Antenna type options, directional or Omni-directional antennas option.

• Easy operation and installation.

• Keep for upgrade module installation.

• Working 24 hours/365days continuously.

Feature:

1.With Power regulation;

2.Jammer body using aluminum, good thermal conductivity, heat quickly;

3.Can be used continuously boot, stable, long life;

4.continuous shielding signal, harmless to human body;

5.signal targeted shielding, does not interfere with other signals;

6.Waterproof, can be installed outdoors;

7.Shield signal segment more, according to customer needs to choose;

8.Module design .Easy to change and repair.

Following is the standard parameters for this prison jammer,OEM/ODM and customrized frequencies are

accpetable as well.

Output Interface Output Frequency
CH1 UHF:450-470MHz optional
CH2 CDMA:851-894MHz optional
CH3 GSM:925-960MHz optional
CH4 DCS:1800-1880MHz optional
CH5 PCS:1900-1990MHz optional
CH6 3G:2110-2170MHz optional
CH7 4G1:2400-2484MHz optional
CH8 4G2:2620-2690MHz optional

Working Bands: 4 to 5 bands selectable ,customrized frequencies optional.

Power Amplifier Protectors:

A. Over Heat protection – Thermal protector

B. Over current protection

C. High input Voltage and low Voltage protection

D. VSWR protection: against antenna miss-match including open and short circuit

RF output power:

Up to 250W

Power Consumption:

750W

Internal Modulation:

Analog

Power supply:

220VAC/110VAC
Continuous working hours: Long time
HS Code: 8543709200
Type: Waterproof
Packing: Box
Advantage prison jammer
Material Metal case

Effective jamming range:

50-200m depending on the the environment signal strength

Sweep rate:

Fixed
Jamming target: CDMA, GSM, DCS, PCS,3G, WIFI, 4GLTE,etc

Antennas type:

high gain directional panel antennas or omni antennas

Dimension:

600×400×250mm

Net Weight:

24kgs

Operating Temp:

-20ºC - +55ºC

Humidity:

5% - 95%



Applicable Area:

Mainly used in
Prisons and other large sensitive locations such as military or government buildings,

the examination room, prisons, gas stations, to prevent mobile bombs, oil depots, liquefied

petroleum gas stations, detention centers, interrogation rooms, courts, labor camps, conference rooms,

theaters, churches, libraries, school dormitories, special security and confidential occasions To do, to

discuss the room, mobile vehicles, mobile politicians and business dignitaries to defend the scene and

other military powerhouse and other places prohibited the use of mobile phones.


Terms and conditions:

Delivery Time Schedule Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 40% advance, 40% after one month,20% before shipping.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year : 5% of total for each years.
