Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Portable Outdoor IP65 All Mobile phone Signal Jammer Backup battery and active smart cooling system
Specifications
Brand Name :
wolvesteam
Certification :
CE
Place of Origin :
China
MOQ :
1 piece
Price :
negotiated price
Payment Terms :
L/C, T/T
Supply Ability :
100pieces/month
Delivery Time :
25 days
Packaging Details :
Box 56*45.5*26.5 CM
Total power output :
80W 12 -20wat/ band
Feature :
High power radio-frequency amplifier and voltage standing wave ratio, self-protection of temperature.
Blocking Range Radius :
Up to 180meters ( signal strength <=-75dbm at the application place.)
Housing :
Metal enclosure
Antennae type :
External high gain directional (standard)
Application area :
Military Units, Prison, Police, Bomb Disposal
Power of each frequency band :
can be adjustable independently
Description

Product Description:

This Portable High Power Wireless Anti-explosion Jammer is the most advanced high efficiency cell phone and satellite signal jammer in the whole world which is professionally designed for bomb disposal and VIP protection like during battle and security safeguard. This certain jammer can block signals in five different frequencies at the same time or separately.

• Remote control can control each module working frequency, output power, etc.
• Equipped with a wired remote control unit. The operator can ON/OFF each module through the wired remote control.
• Fully portable trolley-type case for easy transportation and rapid deployment.
• Supplied by AC mains or DC power source.
• Backup battery system and generator system are optional.
• The jamming system has an active smart cooling system in a continuous working cycle.
• Based on our general design, we can further customize our systems for client-specific scenarios both for military and civil applications in order to provide the best individualized solution.

Specification:

Output Interface

 Output Frequency RF Output dBm

CH1

 PCS/GSM1900 [+PHS] (1930-1990 MHz) 12-20W
CH2 UMTS (3G) (2110-2170 MHz) 12-80W
CH3 CDMA/TDMA+Nextel (851-894 MHz), 12-20W
CH4 IDEN 12-20W
CH5 AMPS (869-894MHz) 12-20W
CH6 GSM850 12-20W
CH7 GSM (925-960 MHz) 12-20W

CH8

High GSM/DCS (1805-1880 MHz)

 12-20W
CH9 4G LTE (US.725-770MHz) or (EU.790-826MHz) 12-20W
CH10 4G Wimax (US.2345-2400MHz) or (EU.2620-2690MHz) 12-20W
Total RF Power 100Watt, 12 -20wat/ band
Power supply ~230VAC / ~110VAC
Shielding area 20-180m @ according to signal density of mobile network
Power Adjustment 16 levels
Cooling System Systematic Smart Cooling System
System Protection VSWR, Over-voltage, Over-current
Housing: Metal enclosure
Control Wireless Management Control by Computer
Antenna Type External high gain directional (standard)
Antenna gain: 3-4 dBi (Omni directional antenna, no cable )
Battery Full charge work time 2hours
Power consumption: 480W
Weight: Approx 28kg (with omnidirectional antenna.)
Size (length × wind × high) 56*46*27 cm
Humidity Up to 80%
Running Temperature -20 ...+50 Centigrade degree

The accessories of this jammer include:

  • Power cable
  • Antennas
  • User manual

Products Application Fields

High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.

It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.

Terms and conditions:

Delivery Time Schedule Delivery time is 1 or 2 months, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 40% advance, 40% after one month,20% before shipping.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year : 5% of total for each years.
