Specifications
Brand Name :
TUXIN
Model Number :
TX-WF*6404
Certification :
ISO 9001:2008/CE/ROHS
Place of Origin :
Zhejiang, China (Mainland)
MOQ :
10/PCS
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000PCS
Delivery Time :
15-20 work days
Packaging Details :
Assembied packing
Cabinet Standard :
International Standard
Material :
SPCC Cold Rolled Steel
Product Name :
4U Wall mount cabinet
Customization :
Accept Enclosure Customized
Surface finish :
Picking , Phosphating , Powder Coated
Capacity :
4U - 24U
Front door :
Toughened Glass Front Door, Mesh door
Loading capacity :
60kg (on the adjustable feet)
Description

4u wall mount network cabinet enclosure cabinet small server rack

Specifications:

1. Capacity:4U

2. Width*Depth:600*450mm

3. Certificate:ROHS CE ISO9001:2008

4. 4U, 6U, 9U, 12U, 15U, 18Uare all available

Features:

  1. Comply with ANSI/EIA;RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7;GB/T3047.2-92 standard;

compatible with 19’’ international standard, metric system and EISI standard.

  1. Advanced technology, precise size.
  2. Reliable structure, static loading capacity:60KG.
  3. Quick and easy wall mounted, 19’’ standard installation inside.
  4. Can be flated pack, save transportation inside.
  5. 120mm size fan could be installed at top of cabinet.
  6. Cable entry from top and bottom.
  7. IP degree:IP20.

Surface finish:

Degreasing, pickling, phosphating, powder coating.

Material and Thickness:

Mounting profile:1.5mm

Others:1.2mm

Color:

RAL9004(black)

RAL7044(gray)

Commercial Wall Mount Network Cabinet Small Server Rack Stable Structure

Brand: TUXIN Column spacing: 465mm (19 inch)
No: TX-WF-6404 Material: SPCC cold rolled steel
Size: 600mm*450mm*4U Function: Can install server equipment,the router,patch panel,KVM,UPS,Network device,etc.
IOS test: Pass ISO9001:2008 Qualtiy System Thickness: Mounting Profile: 1.5mm,others: 1.2/1.0mm
Surface treatment: Degreasing,pickling,phosphating,power coating,etc. Configuration: Cage nuts and M6 screws: 10 sets.
Standard: Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491；PARTI,DIN41494；PART7,GB/T3047.2-92 standard; compatible with ETSI standard. Device Installation: It is recommended to install network equipment/server device within 350 mm depth.

Order Codes Capacity W*D*H(mm)
TX-WF-6404 4 600*450*220
TX-WF-6606 6 600*600*358
TX-WF-6409 9 600*450*492
TX-WF-6612 12 600*600*625
TX-WF-6415 15 600*450*730
TX-WF-6418 18 600*450*820
TX-WF-6422 22 600*450*960
TX-WF-6427 27 600*450*1280

Staff Technology:

The staff has trained strict pre-job training. Our staff has enough production process knowledge, strong sense of quality and self-checking awareness. "Quality is not defective, customer zero complaints" is our goal. We provide customers with satisfactory products and services according to international standards. All of these guarantee the high quality of our products.
