600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
600 X 600mm Small Server Rack Cabinet , Single Section Wall Mount Data Rack
Specifications
Brand Name :
TUXIN
Model Number :
TX-WF*6609
Certification :
CE&RoHS
Place of Origin :
China
MOQ :
20pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
5000pcs/month
Delivery Time :
15-20 days
Packaging Details :
assemble packing with carton. Packing sieze:61.5x46.5x29.5cm
Cabinet Standard :
International Standard
Material :
SPCC Cold Rolled Steel
Degree of protection :
Wall Mounted Cabinet IP20
Application :
Data Center Server Rack
Feature :
Wall Mounted Cabinet Rack
Status :
Stock
Standard :
International
Warranty :
1 year
Description

19 inch 9U 600 x 600mm single section wall mount network cabinet

Staff Technology:

The staff has trained strict pre-job training. Our staff has enough production process knowledge, strong sense of quality and self-checking awareness. "Quality is not defective, customer zero complaints" is our goal. We provide customers with satisfactory products and services according

Features:
1. Simple structure, easy operating and exquisite design
2. Removable side panel, easy to install and maintain, lock optional.
3.Cooling fan optional.
4. Standing or wall mounting installation.
5. Cable entry on both of top cover and bottom panel.
6. Adjustable feet and heavy duty castors are optional.
7. Various optional accessories.
Main material:
SPCC cold rolled steel
Thickness: 1.2mm-1.5mm

Surface finish:
Degreasing, pickling, phosphoric, powder coated.

Loading capacity:
Max static loading: 60kg

Packing&Delivery:

Technical Parameters:

Brand: TUXIN Column spacing: 465mm (19 inch)
No: TX-WF-6609 Material: SPCC cold rolled steel
Size: 600mm*600mm*9U Function: Can install server equipment,the router,patch panel,KVM,UPS,Network device,etc.
IOS test: Pass ISO9001:2008 Qualtiy System Thickness: Mounting Profile: 1.5mm,others: 1.2/1.0mm
Surface treatment: Degreasing,pickling,phosphating,power coating,etc. Configuration: Cage nuts and M6 screws: 10 sets.
Standard: Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491；PARTI,DIN41494；PART7,GB/T3047.2-92 standard; compatible with ETSI standard. Device Installation: It is recommended to install network equipment/server device within 350 mm depth.

Order Codes Capacity W*D*H(mm)
TX-WF-6404 4 600*450*220
TX-WF-6606 6 600*600*358
TX-WF-6409 9 600*450*492
TX-WF-6612 12 600*600*625
TX-WF-6415 15 600*450*730
TX-WF-6418 18 600*450*820
TX-WF-6422 22 600*450*960
TX-WF-6427 27 600*450*1280

Why Us

" Tu-xin Rack Cabinets, Experience The Difference"

Our Vision :Protecting the World's Network Safety through Our Technology Innovation.

Our Purpose: To affect the future of Computer & Networking Rooms

We do all this by...

1. Having a team of committed, consistent and respectful people who are always striving for excellence

2. Our products and services are of the highest quality, constantly striving to use the latest technology

Capabilities…

1. With a modern factory, 10,000 square meters, 5 engineers and over 150 team members producing our brand

2. we have confidence to export world class products that have been continually enhanced for over 10 years of production
