Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof
Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof
Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof
Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof
Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof
Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof
Specifications
Brand Name :
TUXIN
Model Number :
TX-WF*6609
Certification :
CE , ROHS
Place of Origin :
Zhejiang, China (Mainland)
MOQ :
20PCS
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000PCS
Delivery Time :
10-20 work days
Packaging Details :
Assembied packing
Color :
RAL9004 , RAL9005 , RAL7035 , RAL7044
Size :
19 Inch 600mm*600mm*9U
Function :
Dustproof
Feature :
Wall Mounted Cabinet Rack
Status :
Stock
Standard :
International
Warranty :
1 year
Description

19 inch 9u 600mm * 600mm SPCC Cold Rolled Steel wall mount data rack enclosures

Features:

  1. Comply with ANSI/EIA;RS-310-D;IEC297-2; DIN41491:PART1;DIN41494:PART7;GB/T3047.2-92 standard;

compatible with 19’’ international standard, metric system and EISI standard.

  1. Advanced technology, precise size.
  2. Reliable structure, static loading capacity:60KG.
  3. Quick and easy wall mounted, 19’’ standard installation inside.
  4. Can be flated pack, save transportation inside.
  5. 120mm size fan could be installed at top of cabinet.
  6. Cable entry from top and bottom.
  7. IP degree:IP20.

Surface finish:

Degreasing, pickling, phosphating, powder coating.

Material and Thickness:

Mounting profile:1.5mm

Others:1.2mm

Color:

RAL9004(black)

RAL7044(gray)

Data Center Wall Mount Data Rack Enclosures 19 Inch 9u High Standard Fireproof

Brand: TUXIN Column spacing: 465mm (19 inch)
No: TX-WF-6406 Material: SPCC cold rolled steel
Size: 600mm*600mm*9U Function: Can install server equipment,the router,patch panel,KVM,UPS,Network device,etc.
IOS test: Pass ISO9001:2008 Qualtiy System Thickness: Mounting Profile: 1.5mm,others: 1.2/1.0mm
Surface treatment: Degreasing,pickling,phosphating,power coating,etc. Configuration: Cage nuts and M6 screws: 10 sets.
Standard: Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491；PARTI,DIN41494；PART7,GB/T3047.2-92 standard; compatible with ETSI standard. Device Installation: It is recommended to install network equipment/server device within 350 mm depth.

Order Codes Capacity W*D*H(mm)
TX-WF-6404 4 600*450*220
TX-WF-6606 6 600*600*358
TX-WF-6409 9 600*450*492
TX-WF-6612 12 600*600*625
TX-WF-6415 15 600*450*730
TX-WF-6418 18 600*450*820
TX-WF-6422 22 600*450*960
TX-WF-6427 27 600*450*1280

Staff Technology:

The staff has trained strict pre-job training. Our staff has enough production process knowledge, strong sense of quality and self-checking awareness. "Quality is not defective, customer zero complaints" is our goal. We provide customers with satisfactory products and services according to international standards. All of these guarantee the high quality of our products.

Process Control:

We strictly control all incoming materials, spare parts and the quality of the entire production process to ensure the production of high-quality cabinets.
