SPCC Cold Rolled Steel 6u rack dimensions wall mount data rack

Features:

1. Comply with ANSI/EIA;RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7;GB/T3047.2-92 standard;

compatible with 19’’ international standard, metric system and EISI standard.

1. Advanced technology, precise size.
2. Reliable structure, static loading capacity:60KG.
3. Quick and easy wall mounted, 19’’ standard installation inside.
4. Can be flated pack, save transportation inside.
5. 120mm size fan could be installed at top of cabinet.
6. Cable entry from top and bottom.
7. IP degree:IP20.

Surface finish:

Degreasing, pickling, phosphating, powder coating.

Material and Thickness:

Mounting profile:1.5mm

Others:1.2mm

Color:

RAL9004(black)

RAL7044(gray)

Welded frame,stable structure with precise craftsmanship;

Single section,compatiblewith 19"standard equipment;

Tempered glass front door with over 180 turning degree;

Removable side panel,easy to install and maintain(lock optional);

Cable entry on the top cover and bottom panel with knock-out plate;

L-shaped mounting profile,easy to adjustable on the mounting rail;

Fan cutout on the top cover ,easy to install fan;

Swing back with over 90 turning degree;

Various accessories for optional;

We have 6 years experience of production in network rack.
1. About shipping: ningbo or shanghai, Send to your warehouse or your other supplier in China.
2. About Payment: T/T, Western Union; LC; Paypal, 30% deposit 70% before shippment.
3. About QC: Strict quality control system
4. About delivery time: 10-15 days

Why Us

"Tu-xin Rack Cabinets, Experience The Difference"

Our Vision :Protecting the World's Network Safety through Our Technology Innovation.

Our Purpose: To affect the future of Computer & Networking Rooms

We do all this by...

1. Having a team of committed, consistent and respectful people who are always striving for excellence

2. Our products and services are of the highest quality, constantly striving to use the latest technology

Capabilities…

1. With a modern factory, 10,000 square meters, 5 engineers and over 150 team members producing our brand

2. we have confidence to export world class products that have been continually enhanced for over 10 years of production

FAQ
1. Q:Are you a factory or trading company?
A: We are a Factory, Distributor and Trading Company.
2. Q:Where is your factory located? How can I visit there?
A: Our factory and office is located in Ningbo, China.
You can fly to Ningbo or Shanghai airport,Warmly welcome to visit us!
3. Q:Can you do OEM?
A: Sure,we can do OEM products.
4. Q:How can I get some samples?
A: We are honored to offer you samples.
5. Q:How does your factory promise quality control?
A: Quality is priority.We always attach great importance to quality
controlling.Our factory has gained CE,ROHS authentication.
