27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures
27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures
27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures
27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures
27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures
27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures
Specifications
Brand Name :
TUXIN
Model Number :
TX-PB*6627
Certification :
ISO 9001:2008/CE/ROHS
Place of Origin :
Zhejiang, China (Mainland)
MOQ :
10PCS
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000PCS
Delivery Time :
15-20 work days
Packaging Details :
Assembied packing / Flat packing
Color :
RAL9004 , RAL9005 , RAL7035 , RAL7044
Size :
19 Inch 600mm*600mm*27U
Surface finish :
Picking , Phosphating , Powder Coated
Capacity :
15U / 18U / 20U / 22U / 24U / 27U / 32U / 37U / 42U / 47U
Degree of protection :
IP20
Application :
Data Center Server Rack
Thickness :
Mounting Angle : 1.5mm
Type :
19" Standard Server Cabinet
Description

27u small 19 inch server rack SPCC Cold Rolled Steel on wheels with Toughened Glass Front Door

Features:

1. Comply with ANSI/EIA;RS-310-D;IEC297-2;DIN41491:PART1;DIN41494:PART7;GB/T3047.2-92 standard;compatible with 19’’ international standard, metric system and EISI standard.

2. The overall use of the frame structure,easy to install.

3. Front door with perforated,back door steel plate.

4. Using the upper and lower line way,can be closed up

and down the alignment channel.large hole size in

bottom can be adjusted.

5.Can easily remove the left and right side doors and

front/rear doors.

6. Install high-speed silent cooling fan at the top of the

cabinet.

7. The bottom of the installation of the steeling wheel

to facilitate the movement, through the foot so that

the overall balance.

8. Front door with elastic lock,solid and cabinet

connection.

Surface finish:

Degreasing, pickling, phosphating, powder coating.

Material and Thickness:

Mounting profile:2.0mm

Others:1.2mm

Color:

RAL9004(black)

RAL7044(gray)

27u Small White Server Cabinet , Colded Rolled Steel 19 Inch Rack Enclosures

Brand: TUXIN Column spacing: 465mm (19 inch)
No: TX-PB-6627 Material: SPCC cold rolled steel
Size: 600mm*600mm*27U Function: Can install server equipment,the router,patch panel,KVM,UPS,Network device,etc.
IOS test: Pass ISO9001:2008 Qualtiy System Thickness: Mounting Profile: 2.0mm,others: 1.2-1.5mm
Surface treatment: Degreasing,pickling,phosphating,power coating,etc. Configuration: Cage nuts and M6 screws: 20 sets.
Standard: Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491;PARTI,DIN41494;PART7,GB/T3047.2-92 standard; compatible with ETSI standard. Device Installation: It is recommended to install network equipment/server device within 350 mm depth.

Order Codes Capacity W*D*H(mm)
TX-PB*6615 15U 600*600*800
TX-PB*6620 20U 600*600*1000
TX-PB*6624 24U 600*600*1200
TX-PB*6627 27U 600*600*1400
TX-PB*6632 32U 600*600*1600
TX-PB*6637 37U 600*600*1800
TX-PB*6642 42U 600*600*2000
TX-PB*6647 47U 600*600*2200
TX-PB*6824 24U 600*800*1200
TX-PB*6832 32U 600*800*1600
TX-PB*6837 37U 600*800*1800
TX-PB*6842 42U 600*800*2000
TX-PB*6924 24U 600*900*1200
TX-PB*6932 32U 600*900*1600
TX-PB*6937 37U 600*900*1800
TX-PB*6942 42U 600*900*2000
TX-PB*6024 24U 600*1000*1200
TX-PB*6032 32U 600*1000*1600
TX-PB*6037 37U 600*1000*1800
TX-PB*6042 42U 600*1000*2000
TX-PB*8642 42U 800*600*2000
TX-PB*8842 42U 800*800*2000
TX-PB*8042 42U 800*1000*2000

The server cabinet has good technical performance. The server cabinet should have anti-vibration, impact resistance, corrosion resistance, dust-proof, waterproof, radiation protection, etc., in order to ensure the stable and reliable operation of the equipment. The server cabinet should have good usability and safety protection facilities, which is convenient for operation, installation and maintenance, and can ensure operator safety

FAQ
1. Q:Are you a factory or trading company?
A: We are a Factory, Distributor and Trading Company.
2. Q:Where is your factory located? How can I visit there?
A: Our factory and office is located in Ningbo, China.
You can fly to Ningbo or Shanghai airport,Warmly welcome to visit us!
3. Q:Can you do OEM?
A: Sure,we can do OEM products.
4. Q:How can I get some samples?
A: We are honored to offer you samples.
5. Q:How does your factory promise quality control?
A: Quality is priority.We always attach great importance to quality
controlling.Our factory has gained CE,ROHS authentication.
