Technical data | Q90.195.120 | Q90.195.060 |
External dimensions(mm): | 1193*615*1953 | 599*615*1953 |
Internal dimensions(mm): | 1050*522*1647 | 450*522*1647 |
Weight excluding internal equipment(kg) | 424 | 265 |
Pumping(DN) | 75 | 75 |
Ventilation: 10 times(m³/h) | 9 | 4 |
Differential pressure(Ventilation: 10 times)(Pa) | 5 | 5 |
Maximum load(Kg) | 600 | 600 |
Distributed load(Kg/㎡) | 531 | 894 |
Maximum shelf load (evenly distributed) | 7500 | 7500 |
Capacity of bottom collecting tank(L) | 3300 | 2200 |
| | |
Transport base | | |
Height of transport base entrance(mm) | 90 | 90 |
Width of transport base entrance(mm) | 1120 | 526 |
item | value |
General Use | Commercial Furniture |
Type | Laboratory Furniture |
Mail packing | N |
Application | Hospital, School, Other, Lab |
Design Style | Modern |
Material | Metal |
| Stainless Steel |
Place of Origin | China |
| QingDao |
Brand Name | zhengcheng |
Model Number | BK-Q-CLASSIC-90 |
Fire resistance | 90 minutes |
Certificate | CE/GS/EN 16121/16122/EN 14470-1 |
Cabinet | Charcoal grey |
Cabinet door | Warning yellow or light gray |
Operation | Comfortable and relaxed |
Base | Integrated transport (detachable) |
Color | Seven colors available |
MOQ | 1 Set |
Warranty | 1 Year |
Usage | Laboratory Area |
