Plastic Injection Mould In Mould Decoration High Dust Humidity Resistant
Plastic Injection Mould In Mould Decoration High Dust Humidity Resistant
Plastic Injection Mould In Mould Decoration High Dust Humidity Resistant
Plastic Injection Mould In Mould Decoration High Dust Humidity Resistant
Plastic Injection Mould In Mould Decoration High Dust Humidity Resistant
Plastic Injection Mould In Mould Decoration High Dust Humidity Resistant
Specifications
Place of Origin :
CN
Brand Name :
Alever
Certification :
ISO9001:2000,ISO: TS16949
MOQ :
1set
Price :
Up to design
Packaging Details :
Wooden Box
Delivery Time :
15-45days, Up to design
Payment Terms :
L/C, T/T
Supply Ability :
150 set per month minium
Name :
Injection Moulding Die
Surface treatment :
EDM, texture, grinding, mirror polish
Mould life span :
300000~+1,000,000 shots
injection material :
ABS, POM, PMMA, PC, PP, Nylon, PA+GF, PET, TPE, PVC, HDPE etc
Description

Dust / Humidity Resistant Custom Injection Molding In Mould Decoration

Stress
The main enemy of any injection molded plastic part is stress. When a plastic resin (which contains long strains of molecules) is melted in preparation for molding, the molecular bonds are temporarily broken due to the heat and shear force of the extruder, allowing the molecules to flow into the mold. Using pressure, the resin is forced into the mold filling in every feature, crack and crevice of the mold. As the molecules are pushed through each feature, they are forced to bend, turn and distort to form the shape of the part. Turning hard or sharp corners exerts more stress on the molecule than taking gentle turns with generous radii. Abrupt transitions from one feature to another are also difficult for the molecules to fill and form to.

As the material cools and the molecular bonds re-link the resin into its rigid form, these stresses are in effect locked into the part. Part stresses can cause warpage, sink marks, cracking, premature failure and other problems.

Specifications:

1

Mould base

LKM & Hasco & DME standard

2

main material of core and cavity

S136, H13, 2344, 718, 2738, 8407, NAK80…

3

Hardness of mould

soft mould: 38~42HRC hard mould: 48~52HRC

4

Cavity

Single-cavity, Multi-cavity, family mould, interchangeable core/cavity

5

Surface treatment

EDM, texture, grinding, mirror polish

6

Gate type

cold runner, hot runner (Yudo/DME/Hasco)

7

Maximum mould size

800*800 mm

8

Mould life span

300000~+1,000,000 shots

9

Quality

ISO9001-2000 certification

10

injection material

ABS, POM, PMMA, PC, PP, Nylon, PA+GF, PET, TPE, PVC, HDPE etc

11

Lead time

30-40 days

12

Package

Wooden case for tools ,PE bags added export carton for parts

13

Payment term

T/T

14

Trade terms

EXW, FOB, CIF

15

Export country

Italy, Australia ,Hungary,Germany, USA, Canada…

16

Secondary treatment for parts

painting, silkscreen, pad printing, plating, assembly

Competitive Advantage:

double injection, over moulding, insert moulding, in mouding labelling
