Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
Specifications
Brand Name :
ChuangYi
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
2 Set
Price :
Negotiation
Payment Terms :
L/C, Western Union, T/T
Supply Ability :
20sets
Delivery Time :
60-90days
Packaging Details :
Export Standar Packing
Production Capacity :
1 ton/set/day
Raw Material :
Virgin Pulp, Wood Pulp, Surgarcane Bagasse Plate, Virgin Pulp
Automation :
Semi-automatic
Mould Plate size :
1100*800mm/900*600mm
Forming method :
Vacuum Suction
Control Method :
PLC and Touch Screen
Heating Type :
Conduction Oil or Electric
Guarantee Period :
1 Year
Description

Pulp fiber non plastic burger box Machine

Molded pulp is often considered a sustainable tableware material, unlike plastic material, molded pulp is produced from natural fiber, which can be recycled again after its life-cycle of 3-4 months degradable by landfill.

By using virgin pulp ( surgarcane bagasse, bamboo pulp, wood pulp, straw pulp) , this production line can change mold to produce all kinds of tableware such as paper plates and bowls, fast food take-away box, clamshell box, lunch box, cake tray, pizza tray, salad box, cups, cup lids.

Forming, drying and hot-pressing processes are operated in one machine by manual transfer.

Technical Description
Machine Model Manual compostable sugarcane tray dry-in-mold wet press Machine
Mold Platen Size 1100x800mm, 900x600mm
Production Capacity 30-40kg per hour
Machine Automation Manual/ Automatic with adding robots
Workshop Requirement ~ 800㎡
Operator Required 6~9 people/shift
Feeding raw material Virgin pulp ( bagasse pulp/bamboo pulp/wood pulp/straw pulp)
Forming Method Vacuum forming
Drying Method Dry in mold, thermal forming
Machine Function Forming, drying, hot press all in one machine
Control PLC+ Touch screen
Machine Material All parts in contact with water is SS304 Stainless Steel

Production Working Process

Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic

Features:

-Less investment

-Less mold cost

-Lower skill requirement to operator

- Lower precision requirement for mold processing

Production Application:

Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic

Pulp Molding Non Plastic Clamshell Lunch Box Machine Semi AutomaticPulp Molding Non Plastic Clamshell Lunch Box Machine Semi Automatic
