Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Hot Rolled Mold Core P20 Plastic Mould Steel Plate
Specifications
Brand Name :
takford
Model Number :
P20/1.2311/3CR2MO
Place of Origin :
CHINA
MOQ :
1 pc
Price :
usd 0.8-1.5/kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 tons per month
Delivery Time :
5-10 days
Packaging Details :
According to The Demand of The Customer Inquire, Standard Seaworthy Package
Product name :
din 1.2311, Steel plate, plastic mould steel, P20/3Cr2Mo/1.233 pre hardened plastic mould steel plate, DIN 1.2312 10/20mm Thick Plastic Mould Steel Plates
Technique :
Hot Rolled, Forged, EAF+LF+VD+Hot Rolled/Forged, Forged/Hot Rolled/Cold Drawn, Hot rolled/forged/cold draw
Surface treatment :
black or machined, Black Bright Mirror(mill Polishing HL Etc), black surface or mi
standard :
AISI, DIN, ASTM, GB, JIS
Application :
mold steel, tool stee, die steel, special steel
Shape :
plate, sheet, steel plate/flat bar/round bar, plate/sheet/ flat bar, ba
Delivery condition :
raw, According to The Demand of The Customer Inquire, Standard Seaworthy Package
Description

Steel Plate P20 ／ Plastic Mould Steel Plate for plastic mold core

P20 is a standard mold steel pre-hardened to 300HB.

Material properties
Standard prehardened steel designed for plastic mold industry.

For which tools
Plastic injection mould cores and cavities, extension dies for thermoplastics.

For which plastics
Thermoplastics (PE, PP, PS), thermosetting plastics, transparent melts.

Specification

Product Name

alloy steel/carbon steel/steel round bar
Length custom-made
Width custom-made
Thickness any size can custom-made
Standard AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.
Technique Hot rolled/forged/cold draw
Surface Treatment clean/black rough/milled/grinding painting etc.
Thickness tolerance ±0.15mm
MOQ 1 ton to 25 tons and accept sample order
Shipping time 15-20 days after receiving deposit or L/C
Export packing Standrad export seaworthy package/ wooden box package
Capacity 12000 tons/year

Material

3Cr2Mo/1.2311/1.2312/P20/1.2738/718H/P20+Ni/1.2316/1.2083/4Cr13

/sus420j2/420/S136/NAK80H13/1.2344/SKD61/5CrNiMo/SKT4/1.2714

Cr12/D3/1.2080/Cr12MoV/D2/1.2379/SKD11/9CrWMn/O1/1.2510/SKS3 /DC53

40Cr/5140/35CrMo/42CrMo/4140/1.7225

C45/C50/1045/1050/S50C/S45C/T10/T8

M2/1.338/SKH51

CUSTOM-MADE

Chemical composition

Grade C Si Mn Cr Mo P S
DIN 1.2311 0.35~0.45 0.20~0.40 1.30~1.60 1.80~2.10 0.15~0.25 ≤0.03 ≤0.03
AISI P20 0.28~0.4 0.2~0.8 0.6~1.0 1.4~2.0 0.3~0.55 ≤0.03 ≤0.03

Hot Rolled Mold Core P20 Plastic Mould Steel PlateHot Rolled Mold Core P20 Plastic Mould Steel Plate

Hot Rolled Mold Core P20 Plastic Mould Steel PlateHot Rolled Mold Core P20 Plastic Mould Steel PlateHot Rolled Mold Core P20 Plastic Mould Steel Plate
