Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
Specifications
Brand Name :
PRM
Model Number :
Custom
Certification :
ISO9001
Place of Origin :
China
MOQ :
1kg
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
5tons/month
Delivery Time :
5~7days
Packaging Details :
Plywood case
Product Name :
Niobium bar
Grade :
RO4200,RO4210,Nb-Zr1,TaNb20,TaNb30
Diameter :
Φ3.0~Φ100mm
Standard :
ASTM B392
Delivery status :
Annealed
Surface :
Polished
Description

Product Information:

Product Name: Niobium rod

Material: RO4200, RO4210,Nb1,Nb2,NbZr1,TaNb20,TaNb30
Diameter:φ3.0-100mm
Standard: ASTM B392
Purity: ≥99.95%

Surface: polished

State: Annealed state (M)

Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic IndustriesΦ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries

Tolerance Range:

Diameter Tolerance of Diameter (mm) Length (mm)

Fixed length

Allowable deviation (mm)
Forged rod Extruded rod Rolled rod Polished rpd 200~1500 +5
3.0~4.5 ±0.05 —— ±0.05 —— 200~1500
>4.5~6.5 ±0.10 —— ±0.10 —— 200~1500
>6.5~10.0 ±0.15 —— ±0.15 —— 200~1500
>10.0~16.0 ±0.20 —— ±0.20 —— 200~2000

+5
>16.0~18.0 ±1.0 —— —— ±0.05 200~2000
>18.0~25.0 ±1.50 ±1.0 —— ±0.05 200~2000
>25.0~40.0 ±2.0 ±1.5 —— ±0.1 200~2000
>40.0~50.0 ±2.50 ±2.0 —— ±0.2 200~2000
>50.0~65.0 ±3.00 ±2.0 —— ±0.30 200~2000
>65.0~150 ±4.00 ±3.0 —— ±0.30 200~1000

Niobium and niobium alloy rods and wires are widely used in fields such as chemistry, electronics, aviation and aerospace due to their high melting point, corrosion resistance, and good cold working properties.

Niobium crucible, Niobium alloy rod, niobium wire,niobium plate, niobium disc,niobium tube and other tantalum niobium alloy products, if know more information,pls contact with our sales manager:

Φ20mm Φ22mm Φ24mm Φ25mm Niobium Bar For Chemical & Electronic Industries
