(1) Screw dia.: 70mm;

(2) L:D: 30:1; Material of screw: 38CrMoALA; The screw is for 100% PET chips.

(3) Hard tooth reducer: Jiangyin Gearbox manufactuer.

(4) Pressure automatic feedback system to control screw speed.

(5) Melt filter: customized

(6) Pressure sensor and gauges: Zhaohui (Chinaa)

(7) Melt pump:1 set

(8) Power of melt pump: 3.7kw

(9) Heater: Electric .

(10) Spinneret device: 1 Set

(12) Spinneret componets 2 sets.

2. Quenching Tank:1 set

(1) The tank is made by Stainless Steel 304.

(2) Use big window.

(3) Heating power: 18kw

3. Seven roller Stretching unit A: 1 set

(1) Roller size: φ270×750×7, All steel roller.

(2) Power of motor: 7.5KW

(3) Steel cabinet with accurately grind gear.

(4) Driving motor and reducer is from Zhejiang Tongli.

4. Hot water Tank:1 set

(1) Size (L×W×H) : 4000×800×1100 mm

(2) Heating power: 35KW; Electrical heating.

(3) Material is stainless steel 304.

(4) Equip one moisture absorption device: 4KW

5. Seven rollers stretching unit B: 0-160m

(1) Roller size: φ270×750×7,All steel roller.

(2) Power of motor: 15KW

(3) Steel cabinet with accurately grind gear makes the roller run smoothly.

(4) Driving motor and reducer is from Zhejiang Tongli.

6. Single layers hot blast stretching oven: 1 set

(1) Fan power: 2.2KW×2 sets.

(2) Heating power: 23KW

(3) Oven length: 4300 mm

7. Seven rollers stretching unit C: 1 set

(1) Roller size: φ270×750×7, All steel roller.

(2) Power of motor: 15KW

(3) Steel cabinet with accurately grind gear makes the roller run smoothly.

(4) Driving motor and reducer:Zhejiang Tongli Reducer.

8. Single layers hot blast setting oven: 1 set

(1) Fan power: 2.2KW×2 sets,

(2) Heating power: 23KW

(3) Oven length: 5000 mm

9. Seven rollers stretching unit D: 1 set

(1) Roller size: φ270×750×7,All steel roller.

(2) Power of motor: 7.5KW

(3) Steel cabinet with accurately grind gear makes the roller run smoothly.

(4) Driving motor and reducer is from Zhejiang Tongli.

10. Lubricating system: 1 set

11. Waster yarn collector: 1 set

12. Winding collector: 300 spindles

(1) The frame transmission is frequency control, driving motor: 2.2kw

Specification:

Picture:
