0.11-0.18mm Monofilament Extrusion Machine For Hollow Painting Brush 30kg/H
0.11-0.18mm Monofilament Extrusion Machine For Hollow Painting Brush 30kg/H
Specifications
Brand Name :
LEAP
Model Number :
RS
Certification :
CE/ISO90001
Place of Origin :
CHANGZHOU,CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
60 set per year
Delivery Time :
90 working days
Packaging Details :
Acceptable customization
Yarn diameter :
0.12-0.18mm
Pattern :
Hollow
Capacity :
30kg/h
Material :
PET
Application :
Painting
Voltage :
customized
Extruder :
65mm
Noozle :
1 set
Description

Monofilament Extrusion Machine For Hollow Painting Brush 0.11-0.18mm 30kg/h

Product Description:

1. Extruder

(1) Screw A diameter: 65mm; Rotation speed: 0～72rpm.

(2) L:D: 30:1; material of screw: 38CrMoALA ；

(3) Pressure automatic feedback system can adjust the screw speed automatically.

(4) Spinneret device: 1 set

(5) Heater: Electric heating ring to ensure the temperature stabilization.

(6) Metering pump: 2 sets, rotation speed 0-45rpm.

2. Quenching tank: 1 set

(1) The tank is made by stainless steel 304.

(2) The height of tank is horizontal pushing structure is conveniently to disassembly the spinneret.

3. The first seven roller stretching unit

(1) Seven variable diameter rollers, material: steel pipe with hard chrome plating.

(2) Steel cabinet with accurately grind gear makes the roller run smoothly.

(3) Reducer is from Zhejiang Tongli Reducer Co., Ltd.

4. Hot blast oven for stretching.

(1) Oven length: 4000mm

(2) Heating power: 22.5kw, electric heating.

5. The second seven roller stretching unit

(1) Seven variable diameter rollers, material: steel pipe with hard chrome plating.

(2) Steel cabinet with accurately grind gear makes the roller run smoothly.

(3) Reducer is from Zhejiang Tongli Reducer Co., Ltd.

6. Single layers hot blast annealing oven: 3 sets

(1) Fan power: 2.2KW×2 sets.

(2) Heating power: 22.5KW

7. The third seven roller stretching unit

(1) Seven variable diameter rollers, material: steel pipe with hard chrome plating.

(2) Steel cabinet with accurately grind gear makes the roller run smoothly.

(3) Reducer is from Zhejiang Tongli Reducer Co., Ltd.

8. Lubricating system: 1 set

9. Semi-auto winding collector

(1) Winding frame length is as per customer’s request.

10. Electrical control system: 1 set

11. Overall size: 31000×2600×2100mm

Parameter:
Screw diameter Φ65mm
Raw material PET Filament size 0.12-0.18mm
Capacity 30Kg/H Filament shape profile
Screw L:D 30:1 Stretching unit 3 sets
Screw material 38CrMoALA Winder as capacity
Max linear speed 150m/min Instillation power 180Kw
Nozzle holes 168 holes Overall size 35×2.6×2.1m

Pictures:

0.11-0.18mm Monofilament Extrusion Machine For Hollow Painting Brush 30kg/H
