9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
Specifications
Brand Name :
Finergy Tech
Model Number :
Mono PERC 390W~400W 24V solar panel
Certification :
CE, IEC61215, IEC61730, TUV, CQC
Place of Origin :
WUXI, CHINA
MOQ :
136PCS
Price :
0.22~0.23 USD per watt
Payment Terms :
T/T, L/C at sight, Western Union
Supply Ability :
10MW per month
Delivery Time :
10 work days
Packaging Details :
31PCS/pallet, 68PCS/stack
Solar Cell :
9BB 158.75mm mono PERC cell from JA or Tongwei Solar
Cells Number :
72PCS of 9BB moo PERC cells in series welding
Installation :
MC4 compatible connectors for easy connection
Feature :
Stable performance in weak light conditions
Application :
Available for both DC and AC solar power systems
Warranty :
15 years repair and workmanship warranty
Description

FSM390~FSM400M72L (390W/395W/400W) 72*9BB Cells Typical Mono PERC Solar Panels

Electrical Characteristics under STC

Module Type FSM390M72L FSM395M72L FSM400M72L
Maximum Power-Pmax (Wp) 390 395 400
Voltage at Maximum Power-Vmp (V) 41.1 41.4 41.7
Current at Maximum Power-Imp (A) 9.49 9.55 9.60
Open Circuit Voltage-Voc (V) 49.3 49.5 49.8
Short Circuit Voltage-Isc (A) 10.12 10.23 10.36
Module Efficiency-ηm (%) 19.7% 19.9% 20.2%
Operating Temperature -40℃ to +85℃
Maximum System Voltage 1000V/1500V DC (IEC)
Power Tolerance 0~+4.99W
Temperature Coefficients of Pmax -0.350%/℃
Temperature Coefficients of Voc -0.270%/℃
Temperature Coefficients of Isc +0.048%/℃

Mechanical Characteristics

Cell Type G1 MONO PERC 158.75×158.75mm
No. of Cells 72 (6×12)
Dimension 1979×1002×35mm
Weight 22 Kg
Junction Box IP68, 3*20A diodes
Output Cables 4.0mm², 1100mm Length (Optional)
Connectors MC4 compatible
Packing 31PCS/Pallet, 748PCS/40’HC

KEY FEATURES

  • Mono Solar Cell adopts PERC technology to guarantee higher output power and higher module efficiency (up to 20.2%).
  • Excellent Anti-PID performance guarantee limited power degradation for mass production.
  • Advanced glass and cell surface textured design ensure excellent performance in low-light environment.
  • Certified to withstand: wind load (2400 Pa) and snow load (5400Pa).
  • Full production from automatic production lines in accordance with IEC61215 and IEC61730 standards.
  • Three channels of EL inspections and power test before packing.
  • Barcode, material and parameter binding data traceable, searchable and freezing.
  • Typical dimension design with MC4 compatible connectors for PV systems easy installation.
  • Optimum vertically packing solution for long distance transportation safety.
  • 15 years material and craft warranty, 12 years power output no less than 90% and 25 years power output no less than 80%.

Who's FINERGY?

FINERGY Solar Tech headquartered in Wuxi, PR China, is a spin-off of Delin Group. FINERGY launched 3 international ISO certified workshops in the industrial park which produce both mono and poly crystalline solar panels. With the development of emerging market, we enlarged the capacity of solar panels production to 800MW per year.

Quality Control of FINERGY

Quality is the life of FINERGY. The company established a perfect quality control system and implements the whole process quality control of raw materials, production, inspection, warehousing, delivery and etc. Through advanced automatic equipment and production line, it’s able to eliminate human defects and improve products quality. Through digital information systems, we can achieve products quality traceability, provide customers with efficient and quick after-sales service to protect the benefits of customers..

How Does Solar System Work?

9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells

Production Workshop

9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells

A Solar Pump Irrigation System Case

9BB Pv Mono Perc Solar Panels 390W 395W 400W 72 Cells
