Ocean Transportation Nylon Hawser Atlas Rope 6 Strand 56mm X 220 Meters
Ocean Transportation Nylon Hawser Atlas Rope 6 Strand 56mm X 220 Meters
Specifications
Brand Name :
GIRO
Model Number :
atlas01
Certification :
ABS/LR/BV/DNV-GL/RINA/RS/CCS/NK/TEST CERTIFICATE
Place of Origin :
china
MOQ :
1
Price :
USD 01-20/kg
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000kg/year
Delivery Time :
5-8 work days
Packaging Details :
woven bag
Product Name :
6 strand Rope
Diameter :
56mm (Diameter can be customized)
Coil Length :
220m (length can be customized)
Construction :
3/8/12/24 strand
Package :
woven bag
Widely use :
Ocean transportation,heavy industry,shipbuilding, and harbor operation etc.
Description

6 strand nylon composite ATLAS rope for Vessel 48mm x 220 meters

GIRO-6 is a six-strand construction rope made of 100% high tenacity polyamide monofilaments and multifilaments combined to contribute to its high performance in good resistance, long-term stiffness and high breaking loads.

Advantage:

1.Material: Polyamide Mono and Multi

2.Easy to run on mooring winch.

3.Higer tensile strength.

4.Good resistance to chemicals.

5.Excellent abrasion resistance.

6.Long durability.

7.Usable in low temperature.

Application:mooring line,tug line and winch line and other industrial heavy-duty usage.

DIA CIR Linear Density MBL
MM INCH Ktex KN
18 2-1/4 220 84.4
20 2-1/2 275 107
22 2-3/4 345 133
24 3 400 154
26 3-1/4 465 179
28 3-1/2 515 197
32 4 650 248
36 4-1/2 832 314
40 5 1000 377
44 5-1/2 1250 491
48 6 1480 579
52 6-1/2 1600 625
56 7 2000 770
60 7-1/2 2170 839
62 7-3/4 2350 910
64 8 2450 952
68 8-1/2 2800 1079
70 8-3/4 3100 1197
72 9 3350 1246
78 9-3/4 3640 1334
80 10 3840 1445
84 10-1/2 4250 1550
88 11 4720 1730
90 11-1/4 5050 1825
96 12 5850 2109


Main Performance

Material 100% high tenacity nylon 66(mono-and multi-filament)
Construction 6strand twist
Treatment Ocean
Colour of Rope white with marker yarn
Approx.Spec.Density 1.14 Non floating
Maclting Point 215℃
Abrasion Resistance Excellent
U.V.Resistance Excellent
Temperature resistance 70℃ max
Dry & wet conditions Can be stowed wet
Range of use As winch lines,mooring lines,anchor lines and heavy duty
Coil length 220m (length can be customized)
Spliced strength ±10%
Weight and length tolerance ±5%
MBL=Minimum Breaking Load Conform Iso 2307
Other sizes Available upon request
