die cutting rule / steel rule / die cutting rule /
die cutting rule / steel rule / die cutting rule /
Specifications
Place of Origin :
China
Brand Name :
MT
Certification :
CE ISO
Model Number :
2pt/3pt/4pt
MOQ :
50meter
Price :
25USD-50USD/one coil
Packaging Details :
paper box
Delivery Time :
7days
Payment Terms :
T/T L/C
Supply Ability :
1000000meter one month
Description

Specifications

Die creasing rules for die making
1.Various size
2.Made high quality carbon steel
3.Available in one meter length or coil

Die Cutting Blade , Cut-crease rule, Perforating rule for flat die cutting board

1.Type of cutting bevel finish:

Shaved , Ground

2.Types of cutting bevel:

die cutting rule / steel rule / die cutting rule /

CB – Center Bevel

SB – Side Bevel

LCB (CFB) – Facette= Long Center Bevel

LSB (SFB )– Side Facette Bevel= Long Side Bevel

Body Hardness:

Medium hard 38HRC

Super hard 43HRC

Edge hardness:

Medium hard

Edge unhardened :38 HRC

Edge hardened: 54HRC

Super hard

Edge unhardened :45-46 HRC

Edge hardened: 63HRC

3.Specification:

Cutting rule

0.71mm(2pt) x 23.8mm (0.937 inch) x 1000mm--------100PCS / BOX
0.71mm(2pt) x 23.8mm (0.937 inch) x 762mm---------100PCS / BOX


1.05mm(3pt) x 23.8mm (0.937 inch) x 1000mm--- ----70 PCS / BOX

1.42mm(4pt) x 23.8mm (0.937 inch) x 1000mm-------50PCS / BOX

Creasing rule

0.71mm(2pt) x 22.9mm/23.24mm/23.3mm/23.5mm x 1000mm--------100PCS / BOX
0.71mm(2pt) x 22.9mm/23.24mm/23.3mm/23.5mm x 762mm---------100PCS / BOX

1.05mm(3pt) x 22.9mm/23.24mm/23.3mm/23.5mm x 1000mm--------70 PCS / BOX


1.42mm(4pt) x 22.9mm/23.24mm/23.3mm/23.5mm x 1000mm--------50PCS / BOX

5.Application:

Cutting rule: Paper boards, die-cutting paper boxes cardboards,corrugated paper, die-cutting cartons,circuits and others.

Creasing rule: (2PT) paper box folding, indentation,(3PT) carton folding,indentation,(4PT,6PT) thick carton folding, indentation.
