Product Summary
VDS | 30V |
I = 10A | VGS = 10V) |
RDS(ON) < 23mΩ | (VGS = 10V) |
RDS(ON) < 35mΩ | (VGS = 4.5V) |
General Description
The HXY4466 uses advanced trench technology to
provide excellent RDS(ON) and low gate charge. This
device is suitable for use as a load switch or in PWM
applications. The source leads are separated to allow
a Kelvin connection to the source, which may be
used to bypass the source inductance.
Electrical Characteristics (T =25°C unless otherwise noted)
A. The value of RθJA is measured with the device mounted on 1in2 FR-4 board with 2oz. Copper, in a still air environment with TA =25°C. The
value in any given application depends on the user's specific board design.
B. The power dissipation PD is based on TJ(MAX)=150°C, using ≤ 10s junction-to-ambient thermal resistance.
C. Repetitive rating, pulse width limited by junction temperature TJ(MAX)=150°C. Ratings are based on low frequency and duty cycles to keep
initialT =25°C.
D. The RθJA is the sum of the thermal impedance from junction to lead RθJL and lead to ambient.
E. The static characteristics in Figures 1 to 6 are obtained using <300µs pulses, duty cycle 0.5% max.
F. These curves are based on the junction-to-ambient thermal impedance which is measured with the device mounted on 1in2 FR-4 board with
2oz. Copper, assuming a maximum junction temperature of TJ(MAX)=150°C. The SOA curve provides a single pulse rating.
G. The spike duty cycle 5% max, limited by junction temperature TJ(MAX)=125°C.
TYPICAL ELECTRICAL AND THERMAL CHARACTERISTICS
