Metal Oxide Semiconductor Mosfet Power Transistor High Rugged Avalanche
Metal Oxide Semiconductor Mosfet Power Transistor High Rugged Avalanche
Specifications
Brand Name :
Hua Xuan Yang
Model Number :
15P03C2
Certification :
RoHS、SGS
Place of Origin :
ShenZhen China
MOQ :
Negotiation
Price :
Negotiated
Payment Terms :
L/C T/T Western Union
Supply Ability :
18,000,000PCS / Per Day
Delivery Time :
1 - 2 Weeks
Packaging Details :
Boxed
Product name :
Mosfet Power Transistor
Type :
Metal Oxide Semiconductor
Power :
-30V/-60A
R DS(ON) :
6.8mΩ(typ.) @V GS =-4.5V
Feature :
Rugged
Description

Metal Oxide Semiconductor Mosfet Power Transistor High Rugged Avalanche

Mosfet Power Transistor Description

-30V/-60A
R DS(ON) = 4.8mΩ(typ.) @V GS =-10V
R DS(ON) = 6.8mΩ(typ.) @V GS =-4.5V
Reliable and Rugged
Halogen Free Devices Available
(RoHS Compliant)

Mosfet Power Transistor Applications

High Frequency Point-of-Load Synchronous Buck Converter
Networking DC-DC Power System
Power Tool Application

Ordering and Marking Information

C2
15P03
YYXXXJWW G

Package Code
C2:
Date Code Assembly Material
YYXXX WW G:Halogen Free

Note: HUAYI lead-free products contain molding compounds/die attach materials and 100% matte tin plate Termi-
Nation finish;which are fully compliant with RoHS. HUAYI lead-free products meet or exceed the lead-Free require-
ments of IPC/JEDEC J-STD-020 for MSL classification at lead-free peak reflow temperature. HUAYI defines
“Green” to mean lead-free (RoHS compliant) and halogen free (Br or Cl does not exceed 900ppm by weight in
homogeneous material and total of Br and Cl does not exceed 1500ppm by weight).
HUAYI reserves the right to make changes, corrections, enhancements, modifications, and improvements to this pr-
oduct and/or to this document at any time without notice.

Absolute Maximum Ratings

Metal Oxide Semiconductor Mosfet Power Transistor High Rugged Avalanche

Typical Operating Characteristics

Metal Oxide Semiconductor Mosfet Power Transistor High Rugged Avalanche
