4 stations BLDC needle motor winding machine
4 stations BLDC needle motor winding machine
4 stations BLDC needle motor winding machine
4 stations BLDC needle motor winding machine
Specifications
Brand Name :
WEDE
Model Number :
WD-4-ZBW
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
20pcs per month
Delivery Time :
30-55 days
Packaging Details :
ply-wooden case
Default station :
4
Description

Sator needle winding machine is used for brushless motor stator coil winding ,Four-station design. Turn No., wire clamping indexing angle, rotation direction can be set on HMI. Machine has self-diagnosis function. It can do the winding for the stators Pole no:2,4,6,8

4 stations BLDC needle motor winding machine

Modle WD-4-ZBW
Wire OD 0.13-1.1mm
Stator ID 36-60mm
Winding head 4
Max core height 10-60mm
Stator OD 70-132mm
Segment jump No. 1-5
Max speed 500-700rpm
Air pressure 0.5-0.7MPa
Power supply 380V,50/60Hz,26KW
Weight about 900kgs
Size 1690x1260x2020mm
