Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Fully servo motors 4 stations ceiling fan motor winding machine
Specifications
Brand Name :
WEDE
Model Number :
WD-4-WCM
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
15pcs per month
Delivery Time :
30-60 days
Packaging Details :
Ply-wooden case
Default motor :
MITSUBISHI
Default HMI :
DELTA
Default tensioner :
Electronic control
Description

Ceiling fan motor winding machine is to make coils winding into stator.

Stator winding machine has 4 stations and 2 controllers independently give the execution order for the 2/2 stations.

Each controller is working with 1 set servo motors which one is for stator indexing(slots transposition), one is for winding, the last one is for the wires arraying.

UPS in the coils winding machine WD-4-WCM is warmly welcome to the customers who are locating in the non-pre notice electricity break up area.

The program in the ceiling fan motor winding machine can set the starting turns no.speed, the ending turns no. speed and the most windings turns no.speed separately which achieves better windings shape;

Fully servo motors 4 stations ceiling fan motor winding machine

the program can set single slot repair or resume winding after wire break which convenients for the production.

Fully servo motors 4 stations ceiling fan motor winding machine

Electronic tensioner can makes the winding more tight to save the copper wires.

Fully servo motors 4 stations ceiling fan motor winding machine

Stator OD Core length Slot No. Wire OD Turns No.
100-150mm 10-25mm 12-49 0.18-0.5 0-9999
RPM Weight Size
0-3000 300KGS 1025x1105x1780mm
