Armature winding machine double flyers is suitable to do winding for the armature with hook commutator even slots such as power tool, mixer, wiper motor, window lift motor, electric chair motor, vacuum cleaner etc.

Main parameter:

Main Components:
Indexing servo motor: 750WX1 spindle: MITSUBISH

Winding servo motor 1500WX2 spindle: MITSUBISH

PLC: FX3G, MITSUBISHI

Interface module: MITSUBISHI

Extension module: MITSUBISHI

Touch screen: 7”, MITSUBISHI

Electromagnetic valve: SMC

Cylinder: SMC and CKD(2 pieces)

Air source handling unit: AIRTAC

Buffer: AIRTAC

Floating joint: AIRTAC

Winding transmission base: cast iron

Indexing transmission base: nodular cast iron

Winding flyer: aluminum die-cast alloy, double spindle balancing adjustment (easy for disassembling)

Indexing spindle: design according to customer’s commutator

Winding tooling: Cr12,integral quenching HRC50-55

Loading structure: cylinder loading (linear bearing + guiding rod)

Provided your armature is with riser commutator, you can use WD-2B-TAW
