140.5g Sealed Power Pistons Fit HM8A4 , 68.5mm CLY DIA Automotive Piston
140.5g Sealed Power Pistons Fit HM8A4 , 68.5mm CLY DIA Automotive Piston
140.5g Sealed Power Pistons Fit HM8A4 , 68.5mm CLY DIA Automotive Piston
140.5g Sealed Power Pistons Fit HM8A4 , 68.5mm CLY DIA Automotive Piston
140.5g Sealed Power Pistons Fit HM8A4 , 68.5mm CLY DIA Automotive Piston
140.5g Sealed Power Pistons Fit HM8A4 , 68.5mm CLY DIA Automotive Piston
Specifications
Model Number :
HM8A4
Place of Origin :
China
MOQ :
Negotiable
Payment Terms :
D/P
Delivery Time :
30 work days
Packaging Details :
1,000,000 sets per month
Price :
Negotiable
Material :
Aluminum
Packing :
Lidon package
Quality :
A class
Color :
Silver
CYL DIA :
68.5mm
Pin Size :
15x50mm
Weight :
140.5g
PR DIA :
68.5x1.0x1.0x2.5mm
Description

68.5mm CLY DIA Motorcycle Engine Pistons Motor Engine Parts HM8A4


Specification

Brand Name
LIDON
Place of Origin
Guangzhou, China
Product name Motorcycle HM8A4 Piston Kit
Quality A class
Material Aluminum Alloy
Color As picture show
Application Motorcycle Engine System
weight
140.5g
Packing Boxes+ Carton
CYL DIA 68.5mm
Pin Size 15*50mm
Shipment Sea, Air, Express


Description


Piston kits are included piston, piston pin and piston rings.
The piston diameter: 68.5mm
The piston pin diameter: 15mm
The length of piston pin: 50mm

The piston ring diameter: 68.5*1.0*1.0*2.5mm

Piston is the reciprocating part of the engine. It can be divided into top, head and skirt. The top of the piston is the main part of the combustion chamber, and its shape is related to the selected combustion chamber form. Gasoline engines mostly use flat-top pistons, which has the advantage of small heat absorption area. But for diesel engine, there are always various pits on the top piston, and their specific shape, position and size must be adapted to the requirements of diesel engine mixture formation and combustion.

Product Model

ITEM NO. MODEL Weight(g)
1 SUZUKI HJ125 93
2 CM150/VESPA150 85
3 S125 83
4 BM150 82
5 LF155 90
6 ARA 68.5
7 HM8A4 140.5
8 KPH125/KTCA 79.2
9 YAMAHA FZ16 96
10 YAMAHA ZY125 72
