Double Guide Rails Precision Manual Lifting Platform Z-Axis Moving Stage

The double guide manual lifting platform PT-SD14-100 is made of high-strength aluminum alloy, with its surface oxidized and blackened. It adopts the cross roller guide rail displacement structure, and is driven by the differential head. It has the characteristics of high-precision, small, smooth, and rigid finite linear movement. It can be used for high-precision, medium, and heavy production machinery inspection devices, precision positioning, and quantitative movement.

Features of double guide manual lifting platform

1. Double guide rail design is adopted, which is more stable than single guide rail, with more load and longer service life.

2. The main body is made of aluminum alloy, which is light in weight and suitable for other devices.

3. The installation is simple. A cross roller guide rail is installed between the high-precision machined workbench and the base. The slide 4 and seat mechanism can be installed with bolts where necessary to obtain a high-precision linear guide mechanism.

5. Because the rollers with large rated load are installed together according to a short pitch, they can bear heavy load and are high.

Wide range of applications

It can be used for all kinds of production machinery with high precision, medium and heavy load.

Check the precision positioning and fixed displacement of the device.

Manual lifting platform product parameters:

There are many kinds of manual displacement tables with complete combination methods. It is widely used in scientific research institutions, automatic measurement and inspection, industrial automation and other fields, and can realize automatic displacement control in vacuum, pollution, sterility, radiation and other environments. From the moving direction, it can be divided into horizontal displacement direction, namely X axis (Y); Vertical lifting direction, i.e. Z-axis; Vertical rotation direction, i.e. R axis: horizontal rotation direction, i.e. G axis. Any combination of the axes can form a spatial XZY three-axis motion, a spatial XYZR four-axis motion, a spatial XYZRTx five axis motion, and a spatial XYZRTxTy six axis motion, thus helping to meet the user's various spatial requirements and the precision displacement of each degree of freedom.

The products of PDV include translation table, lifting table, rotary table, tilting table, angle table, integral multi axis displacement table, etc. The products are divided into multiple series according to the stroke, rotation angle, guide rail form, driving mode, etc. They can be combined freely to meet your needs for displacement stroke, bearing, dimension to be adjusted, etc. If our existing conventional products can not meet your needs, Please be sure to contact us and specifically mention that our experienced full-time engineers are very willing to discuss solutions with you.
