Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV
Specifications
Brand Name :
ADTEK / OEM
Model Number :
J4U2U2293MP-YL
Certification :
ISO, UL, CE, ROHS,CM,CMR
Place of Origin :
Guangdong, China
MOQ :
1 Piece
Price :
$0.89 - $3.25/ Piece
Payment Terms :
T/T
Supply Ability :
100000 Piece/Pieces per Week
Delivery Time :
3-14days
Packaging Details :
Each fiber optic patch cord is individually packed, and then will be packed in a 38.5*19*23cm K=K carton. OEM packing is acceptable.
Name :
Fiber Optical Patch Cord
Diameter :
0.9mm,1.2mm,1.6mm,1.8mm,2.0mm,3.0mm.etc
Testing :
100% Tested, Interferometer Test is acceptable
Buffer Type :
Tight Buffer, Loose Buffer, Semi-Tight Buffer
Polish :
PC/UPC/APC
Real factory :
Yes
Description

Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV

Range of Mode Single mode or Multi mode
Cable Type Simplex, Duplex Ziocord. or Multi-cores
Connector Style SC, FC, ST, LC, MTRJ, E2000, MU, MPO /MTP.etc
Polish or Ferrule Interface Type PC, UPC, APC
Cable Diameter 0.9mm, 1.2mm, 1.6mm, 1.8mm,2.0mm, 3.0mm
Outer Jacket PVC /LSZH/OFNP
Jacket Color SM Yellow | OM1, OM2 Orange | OM3 Aqua | OM4 Aqua or Violet | OM5 Lemon Green
Durability 500 cycles(0.2 dB max increase). 1000mate/de mate cycles
Operating Temp. -25℃ to +70℃
Storage Temp.

-40℃ to +85℃

Application:
1. CATV
2. Active dvice termination
3. Telecommunication networks
4. Metro
5. Local Area Networks(LANs)
6. Data Processing networks
7. Test Equipment
8. Premise installations.
9. Wide Area Networks(WANs)


Feature
1. Low insertion loss and back reflection loss
2. Good echangeability
3. Good Durability
4. High temperature stability.
5. Standard: Telcordia GR-326-CORE
6. Precise connector
7. Excellent mechanical capability

Connector Type Performance Level
Standard Elite
Connector Mode Endface IL(dB) RL(dB) IL(dB) RL(dB)
LC/SC/FC/ST SM PC ≤0.2 ≥50 ≤0.15 ≥50
UPC ≤0.2 ≥55 ≤0.15 ≥55
APC ≤0.2 ≥60 ≤0.15 ≥60
MM PC ≤0.2 ≥35 ≤0.15 ≥35
MPO/MTP SM APC ≤0.7 ≥60 ≤0.35 ≥60
MM PC ≤0.5 ≥20 ≤0.35 ≥20
MTRJ SM PC ≤0.5 ≥50 / /
MM PC ≤0.5 ≥35 / /

1. High precision ceramic insert with small concentricity error and bore diameter to provide better insertion loss and return loss to avoid degradation of transmission performance and damage to optical transceiver devices.
2. Advanced grinding technology and grinding equipment are used to ensure that the surface of the optical fiber is free of scratches and defects, and that the technical parameters such as the circular grinding offset of the fiber, the depression of the fiber and the radius of curvature of the ceramic end face meet the specified standards.
3. The components are all optically tested and tested in accordance with ROHS standards.
4. ANSI / TIA / EIA and ISO / IEC requirements for durability, moisture resistance, coupling stress, fiber tensile force and adaptability to harsh environments such as humidity, temperature extremes, insertion and removal forces and cable tensile stress, impact and vibration.
5. Low insertion loss, high return loss, good interchangeability, excellent repetitive plugging performance and ease of use.
6. Operating temperature (-40℃~+75℃), storage temperature (-40℃~+85℃).

Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV

Single Mode Fiber Optic Patch Cord LC To ST Duplex 0.9mm 1.2mm 1.6mm For CATV

Our Value:

Initiative, Hard working ,Efficiency,Innovation, Grateful, Sharing.

Our Philosophy:

Professional casts quality,cooperation makes win-win future.

Our Solutions:

Fastest, Effective, Reliable, Flexible And Professional OEM/ODM Solutions.

Our Certificate:

ISO9001:2015, ISO14001:2015,OHSAS18001:2007 etc.

Our Team:

We serve our every customer with fastest and most professional response.

Our Patents:

We have 20 patents and we'll go on creating new products to master latest market trend.
