100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use
100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use
100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use
100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use
100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use
100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use
Specifications
Brand Name :
HL
Model Number :
100ZBG Series
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000 Sets/month
Delivery Time :
6-8 weeks
Packaging Details :
standard export packing
Head :
24.3-94.2m
Flow :
95.7-360m³/h
Usage :
Pump water, slurry, sweage, drill rigs, mining etc.
Power :
Electric, Hydraulic
Theory :
Centrifugal Pump
Material :
Cast Iron & Stainless Steel
OEM :
Can be Accept
Description

100ZBG Series Slurry Pump--Outlet Diameter 100mm Large Head Pump

100ZBG Submersible Water Pump, Cast Iron & Stainless Steel , Large head, Mining, Big Capacity, Industrial & Domestic Use

In order to meet the demands in various fields of electric power, metallurgy, coal-mining, construction material and chemicals, on the basis of decades of years' experience in terms of design and manufacture of slurry pump, learning from the advanced science and technology both at home and abroad the corporation has developed the latest ZBG, ZBD and ZBQ series of slurry pump of energy-saving, anti-corrosion and anti-wearing attributes according to the features of the drive of slurry.

ZBG and ZBD series is of 4.3-6000 m3/h flow speed and 8.6-126m head. Especially ZBG series can be an ideal energy-saving product to replace WARMAN with the medium density and anti-corrosion in HH series, among which ZBG (P) series of slurry pump can be used in multi-stage in a series within permissible maximum pressure of 3.6 Mpa. ZBD series is another ideal one to replace WARMAN pump of high density and anti-corrosion in AH series.

Naming Rules

100ZBG-500A

  • 100-- Discharge Diameter(mm).
  • ZB-- Slurry Pump.
  • G-- High head pump (the pump whose head is equal to or larger than 60m and whose outlet diameter less than 125mm while high speed driving, or the pump whose head is equal to or larger than 85m and whose outlet diameter larger than 125mm);
  • D-- Low head pump;
  • Q-- Light pump..
  • (P) --Multi-stage in series, no mark for 1-2 stages.
  • 500-- The nominal diameter of basic impeller (mm).
  • A-- The first cutting of blade diameter (B, C, D represent the second, third and fourth cutting, no mark for basic type).
  • J-- Seal Type (J: Mechanical seal; T: packing seal; impeller seal combined with packing has no signal)

Specification

Model Rotating Speed Flow Head Eff. Shaft Power Required
NPSH		 Motor Transmission form Diameter
n Q H η Pa Power Poles Number Outlet Inlet
r/min m3/h m % kW m kw p mm mm
100ZBG(P)-500 1480 180.0 94.2 55.7 82.9 3.4 132 160 185 4 Isokinetic 100 152
300.0 90.0 68.0 108.2 4.3
360.0 86.1 70.4 119.9 5.5
100ZBG(P)-500 1450 176.4 90.4 55.6 78.2 3.3 132 160 185 4 Variable Speed 100 152
293.9 86.4 67.8 101.9 4.1
352.7 82.6 70.2 113.0 5.3
1400 170.3 84.3 55.4 70.6 3.0 132 160
283.8 80.5 67.6 92.1 3.8
340.5 77.0 70.0 102.2 4.9
1350 164.2 78.4 55.1 63.6 2.8 110 132
273.6 74.9 67.3 82.9 3.6
328.4 71.6 69.7 92.0 4.6
1300 158.1 72.7 54.9 57.0 2.6 110 132
263.5 69.4 67.0 74.4 3.3
316.2 66.4 69.4 82.5 4.2
1250 152.0 67.2 54.6 50.9 2.4 90 110
253.4 64.2 66.7 66.4 3.1
304.1 61.4 69.1 73.7 3.9
1200 145.9 61.9 54.4 45.3 2.2 75 90
243.2 59.2 66.4 59.0 2.8
291.9 56.6 68.7 65.5 3.6
1150 139.9 56.9 54.1 40.0 2.1 75 90
233.1 54.3 66.1 52.2 2.6
279.7 52.0 68.4 57.9 3.3
1100 133.8 52.0 53.8 35.2 1.9 55 75
223.0 49.7 65.7 45.9 2.4
267.6 47.6 68.1 50.9 3.0
1050 127.7 47.4 53.5 30.8 1.7 55 75
212.8 45.3 65.4 40.2 2.2
255.4 43.3 67.7 44.5 2.8
980 119.2 41.3 53.1 25.2 1.5 45 55 6 Isokinetic
198.6 39.5 64.8 32.9 1.9
238.4 37.8 67.1 36.5 2.4
100ZBG(P)-500A 1480 171.8 85.8 55.4 72.5 3.4 110 132 160 4 Isokinetic
286.4 82.0 67.6 94.6 4.1
343.6 78.4 70.0 104.9 5.1
980 113.8 37.6 52.8 22.1 1.5 37 45 6
189.6 36.0 64.5 28.8 1.8
227.5 34.4 66.8 31.9 2.2
100ZBG(P)-500B 1480 163.2 77.5 55.1 62.5 3.4 110 132 4 Isokinetic
272.0 74.0 67.3 81.5 3.9
326.4 70.8 69.6 90.4 4.7
980 108.1 34.0 52.5 19.0 1.5 37 45 6
180.1 32.4 64.1 24.8 1.7
216.2 31.0 66.4 27.5 2.1
100ZBG(P)-500C 1480 154.1 69.1 54.7 53.0 3.4 90 110 4 Isokinetic
256.9 66.0 66.8 69.1 3.8
308.3 63.1 69.2 76.7 4.4
980 102.1 30.3 52.1 16.1 1.5 30 37 6
170.1 28.9 63.7 21.1 1.7
204.1 27.7 65.9 23.4 1.9
100ZBG(P)-500D 1480 144.5 60.7 54.3 44.0 3.3 75 90 4 Isokinetic
240.8 58.0 66.3 57.4 3.7
289.0 55.5 68.7 63.6 4.1
100ZBG(P)-500D 980 95.7 26.6 51.7 13.4 1.4 22 30 6 Isokinetic 100 152
159.5 25.4 63.2 17.5 1.6
191.4 24.3 65.4 19.4 1.8
