32ZBG-160 Slurry Pump

• With the comprehensive application of latest designing theory, the optimization of methods and CAD, CFD and CAPP in pump-design, the slurry pump is of sound hydraulic performance, high efficiency and low abrasion and corrosion.
• Besides the wide passage, non-clogging and anti-corrosion of vapor is also superb.
• The impeller seal combined with packing seal and metric seal ensures no-leakage of slurry.
• The reliable design grants the tremendous improvement in MTBF.
• The adoption of metric bearing with oil lubrication, reasonable structure of cooling system with oil lubrication guarantees the working of bearing in the optimal temperature.
• The suction and discharge flange of the pump is processed against the current standard in china to facilitate the fixation in pipeline.
• And it is engineered in ways of direct connection drive, thus resulting in enhanced efficiency. According to customers’ requirement the belt-convey can also be utilized.

• Clear Water Performance Parameter of ZBG and ZBD Series Slurry Pumps At The Same Speed

• Type	Speed n r/min	Capacity Q m3/h	Head H m	Eff. n %	Matching Motor Power kw	Speed n r/min	Capacity Q m3/h	Head H m	Eff. n %	Matching Motor Power kw
  		10.8	91.7	22.1			5.3	22.0	19.0
  32ZBD-160	2900	18.0	32.0	43.6	5.5-7.5	1400	8.7	7.5	38.4
  		21.6	30.3	46.1			10.4	7.1	40.7
  		10.1	30.1	32.6			6.1	11.0	30.0
  32ZBD-160A	2900	16.8	28.0	43.1	4-5.5	1400	10.2	10.3	39.6
  		20.2	26.5	45.6			12.2	9.7	41.8
  		9.4	25.8	32.2			5.7	9.5	29.6
  32ZBD-160B	2900	15.6	24.0	42.6	3~4	1400	9.5	8.9	39.1
  		18.7	22.7	45.0			11.4	8.4	41.3
