Wall-Mounted B2H6 Diborane Gas Detector in Electronics Industry with 0-10ppm Range

Product Overview

The SG100 gas detector, an intelligent and hot-swappable device, ensures seamless maintenance post-installation, continuously monitoring toxic gases, oxygen, and combustible gases. Certified by IECEx and ATEX, it boasts an explosion-proof rating of Ex db IIC t6 gb/Ex db IIC t6 gb/Ex da db IIC t6 gb. The detector comes equipped with a 3-wire 4 to 20 mA analog output relay, supporting both HART and RS485 Modbus protocols for compatibility with the majority of control systems. Additionally, its magnetic rod design facilitates menu navigation in explosive environments, adding to its versatility and user-friendliness.

Why Choose Us?

• Round-the-Clock Monitoring: We offer 24/7 online monitoring with real-time data visualization, ensuring continuous vigilance and peace of mind.
• Proven Expertise: With 16 years of experience in gas detection, we have built a solid reputation for precision and reliability. Our top-tier sensors, globally sourced, guarantee accurate results, as attested by independent testing institutions.
• Simplified Maintenance: Our modular gas chamber design allows for quick and easy replacement of the air chamber component, eliminating the need for dismantling the entire machine. This ensures seamless on-site maintenance and operation, even in high-risk, explosion-proof environments.
• Safety & Reliability: Our explosion-proof circuit design meets the highest Class A safety and reliability standards. Our instrument boasts triple certifications: IECEx, ATEX, and Chinese explosion-proof approvals.
• Flexible Data Transmission: We provide a comprehensive range of data transmission options, including standard 4-20mA current signal, RS485 digital signal, and 1 set of relay signal output. Optionally, we offer 2 sets of relay signals with voltage 1-5V, standard Hart, and wireless transmission methods like LORA and 4G.

Picture details

Specification
