Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
Specifications
Brand Name :
SAFEGAS
Model Number :
SG100
Certification :
ATEX/IECEX
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100 pieces/day
Delivery Time :
3 work days
Packaging Details :
Aluminum Suitcase Packing
Gas Detected :
Toxic gases, oxygen, flammable, VOC gases
Measure range and Resolution :
Specified according to application
Accuracy :
≤±2-5%FS (Depending on the specific sensor)
Explosion-proof grade： :
IECEX：Ex db IIC T6 Gb，Ex db ia IIC T6 Gb ； ATEX：Ex db IIC T6 Gb，Ex db ia IIC T6 Gb
Protection grade :
IP66/68
Power dissipation :
Toxic gas<2.5W，flammable gas<4W
Communication mode :
4-20mA(3-wires)、RS485 1～5V，Hart(Optional)
Wireless :
LORA, 4G(Optional)
Relay :
3 relays, including low/high/fault alarm relay（Optional）
Working temperature :
0℃～70℃（Catalytic sensor）， -20℃～50℃（Electrochemistry sensor）
CableEntries :
1 x ¾ NPT & 1 xM 20 Cable Entry Connections
Size :
157.8x128.8x69.6mm
Weight :
1.0Kg
Description
Product overview
Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring
SG100 series is a cost-effectivegas detector for continuous monitoring oftoxicgases, oxygen,flammable, VOCgases.
It isIECEx, ATEXcertified,with intrinsically safe explosion grade.Havinga2 wire or 3 wire4 to 20 mA analog output, RS485 modbus output, optional HART output,making it to be compatible with mostcontrol systems. .
With optional wirelessdata transmission,customer is able to review, download the data remotely.Supportbothmagneticandremote control,flexibleforsetting.

Product Feature

Safegas Fixed Gas Detector Voc Gas Toxic Gas Wall-Mounted Continuous Monitoring●IP66/IP68 water & dust resistant

●Intelligentplug and play sensor module.the module supportcalibration by Safegas PC software, making replacement and maintenance easier.

●With standard splash guard to protect sensor for outdoor installation or environment with water splash.

●Smalland light,weight is only 1 kg,andthe detector comes with standard mounting bracket,easy for installation.

●Standard 4-20 mA analog signal output andRS485 modbus signal output,optional Hart output, 2wire output.Compatible with most of control systems.

●The detector comes with 3relays, including low/high/fault alarm relay(Optional)

●Support both magnetic andremote control, flexible for setting.
