55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
Specifications
Brand Name :
TOPADKIOSK/OEM
Model Number :
TPK-R5523
Certification :
CE/FCC/ROSH
Place of Origin :
China
MOQ :
1PC
Price :
Negotiate
Payment Terms :
T/T, , MoneyGram
Supply Ability :
3000pcs per month
Delivery Time :
10-15days after receipt of your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Resolution :
1920*1080/3840*2160
Input Voltage :
AC100~240V 50 /60 HZ
Material :
Metal Case + Toughened Glass
Interface :
HDMI VGA DVI Output USB
speaker :
10W*2
Touch points :
10-points touch
Optional function :
Printer, Card Reader, Wifi, 3G
Installation :
Floor Staning
Description

55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia

※ Excellent design with apple shape, aluminum edging；

※ 43” brand new original panel with LED backlight;

※ 32”, 49'' 55” size also available;

※ Support Windows OS or Android OS;

※ Support to play program directly from USB or through networking;


※ Support digital signage software HD-DS as a total solution;

※ Support posters;

※ Perfect for the hotel reception as a polite to new visitors;

※ Industrial level design, support 24/7 working

Model No. TPK-R5523 Indoor
Material of shell 3mm Aluminium,1.5mm mild steel, 5mm temperglass, Industrial high level Podwer coating.
Certification FCC,RoHS,CE
Interface USB,HDMI,VGA,…..
Guarantee 1 year
Speaker 10Wx2
Storage Medium Flash memory card(2gb to 36gb for the capacity)
Video formats MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1)
Audio formats MP3
Photo formats JPG,bmp
Audio output stereo L/R, 5Wx2, 8Ω
Storage Temp. -7 to 65 Celsius degree
Normal Working Temp. -5 to 65 Celsius degree
Language The default is Chinese and English, others need to be confirmed
Power Supply AC 110V - 240V, 50/60HZ

Specification of LCD display
Size of Screen 42 inch
Ratio 16:9
Display Area 1020mm(H)x 574mm(V)
Dot Pitch 0.485mm (H) x 0.485mm (W)
Max Resolution 1920x1080
Number of Colors 16.7m
Brightness 500cd/m2
Response Time 8s
Contrast 1000:1
Viewing Angle 178°
Using Life 50000 hours

Accessories
AC power line
Remote Controller
Base
Warranty Card
Flash Memory Card
Security Keys
User Manual

Items Specification Unit
Panel Size 42 inch 49 inch 55 inch 65 inch inch
Panel Type TFT-LCD /
Display Colors 8 bit, 16.7 Million colors
Number of Pixels 1920 x 1080 pixel
Luminance of White 450 (Typ.) cd/m2
Contrast 3500:1 (Typ.) /
Viewing Angle 160/120 (H/V)-Fullview degree
Aspect Ratio 16:9 /
Response Time 6.5 (Typ.) m-sec
Life Time 60,000 hours

PC Specifications

Solution: Intel i3
Parts Specification
Processor Intel i3 3240 (3.4GHz, dual core)
RAM 4G DDR3 (Kingston)
Hard Disk 500G 5400rpm (Seagate)
Mother Chipset Intel H61 chipset, Sandy Bridge
Video Chipset Intel HD Graphics, Shared memory
Audio Chipset Intel HD audio
I/O ports 4xUSB 2.0, 1xRJ-45, 1x3.5mm jack plug, 1xHDMI, 1xVGA, 1xDC 12V
Internet Default: RJ-45 and Wi-Fi. Optional: 3G
Loudspeaker 2 x 8Ω/ 5W
OS Android, Linux, Windows XP, Vista, 7/8 (32 bit) / extra cost for original version
OS Language English (default)
Touch Performance
Touch Screen Type Infrared
Touch Condition Finger, touch pen or anything un-transparent
Touch Points 6 points. Optional: 4, 8, 16, 32 points
Interpolation Resolution 32767 x 32767
Response Time ≤ 20m-sec
Min Touch Diameter 5mm
Touch Accuracy ±2mm for 90% area
Platform 4mm thickness tempered glass
Appearance
Color White (default), black and customized
Case 2mm cold-rolled sheet
Paint Process 170°~ 180°Baking finish
Application Floor stand
Others
Power Input AC 100 ~ 240V, 50/60 Hz
Max. Power Consumption 122KWh
Standby Power Consumption <5KWh
IP Code IP20
Working Temperature 0 ~ 40°
Storage Temperature -20 ~ 55°
Working Humidity 20% ~ 80%
Storage Humidity 10% ~ 90%
Unit Package PE film + Foam corner protector + Carton
Export Package Export wooden packing
Accessories Driver CD
Warranty 1 Year

  • Support screen rotation, landscape and vertical display meet your different advertisement requirement.
  • Customizable design to provide style and ergonomic ease of operation.
  • LCD display projects from 8" to 108' in various brightness can be tailor-made according to your specific requirements.
  • We can provide the remote controlling software for you to update your advertisement by internet for digital media advertising application, Android operating system equipped with remote managing software App, once signed up, one life using. Engineers help you inplement the installing and testing of the software and 24 hours on-line help.
  • If you have your own interactive software, infrared touch function is optional. The window OS is also optional for pc application.
  • Ultra HD resolution, panel brand: Sumsung/LG/AU.
  • Password is used to protect the indoor digital totem from being using by stranger.
  • Anywhere and anytime can visit the managing backstage.

55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia

55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia

55 Inch Floor Stand Digital Kiosks Touch Screen Digital Signage LCD Multimedia
