Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen
Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen
Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen
Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen
Specifications
Brand Name :
TOPADKIOSK/OEM
Model Number :
TPK-DID4901
Certification :
CE,FCC.ROSH
Place of Origin :
China
MOQ :
1PC
Price :
Negotiate
Payment Terms :
, MoneyGram, T/T
Supply Ability :
3000PC per month
Delivery Time :
3-5 working days after receipt of your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Type :
TFT
Max Resolution :
3840x2160
Weight :
30kg
Viewing Angle :
178
Pixel Pitch :
0.4845(H)*0.4845 (V)
Dimension :
1075.58mm(W) x605.8mm
Ports Connect :
HDMI/DVI/VGA/DP
Power consumption :
250W
Display area :
1073.8(H)x604(V)
Touch screen :
Infrared multi touch
Description

Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen

Key Features:

Description of LCD Video Wall
♦ Excellent super narrow bezel design with just 3.5 mm bezel width between screens
♦ Built-in 3D noise reduction, making the image clean and outline more vivid
♦ FHD display 1920x1080
♦ LED backlit technology brings you perfect visual effect
♦ 4K input supported (Option)
♦ Built-in speakers and remote control supported
♦ Available sizes: 42",46”, 47”, 49, 55”, 60”

Advantages of LCD Video Wall
♦ Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
♦ High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
♦ Low power consumption and low heat radiation
♦ Long service life lowers the cost of usage and maintenance
♦ Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
♦ Economical and practical: High performance and high quality make it cost less.


Specifications

LCD Video Wall
Model No. TPK-DID4901
Panel Size 49" LCD Screen
Backlight Type LED
Display Area 1073.8(H)x604(V)
Aspect Ratio 16:9
Max Resolution 1920X1080
Color 8Bit,16.7M
Brightness (nits) 700cd/m2
Contrast 3500:1
Visual Angle (H/V) 178°/178°
Response Time 8 ms
Life Span >60,000 hours
Bezel width (between screens) 3.5mm
Product Dimension 1022(L)*576.6H)*124.8(D)
Product Weight 25KG
Interfaces (option 1- without 4K input)
Model No. TYL-DP4609
Input 1*DVI
1*HDMI
1*VGA (SVGA / XGA / WXGA)
2*BNC (PAL/NTSC)
1* YPBPR
1*RS232(RJ45)
Output 1*RS232(RJ45)
1*BNC (PAL/NTSC)
Interfaces (option 2- With 4K input)
Model No. TYL-DP4615-H4
Input 1*DVI
1*HDMI
1* DP (Display port)
1*VGA (SVGA / XGA / WXGA)
2*RS232(RJ45)
Output 1* DP (Display port)
2*RS232(RJ45)
Power
Power Supply AC100V~240V 50/60Hz
Maximum Power Consumption 170W
Standby Power Consumption <3W
Working Environment
Working Temperature 0℃~60℃
Working Humidity 5%-95%RH


Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen

Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen

Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen

Samsung Narrow Bezel LCD Video Wall 3X3 Touch Screen LCD Wall Display Screen
