Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Specifications
Brand Name :
HJY
Model Number :
HJY-DWDM-4CH-19INCH-BIDI-3
Certification :
CE, ROHS, FCC
Place of Origin :
China
MOQ :
1pc
Price :
Please find sales@huajiayu.com
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000000pcs/month
Delivery Time :
3~7 working days
Packaging Details :
Neutrial Standard Packing
Number of Channels :
4 channels
Type :
CWDM mux or demux
Form Factor :
1U Rack Mount
Com Port :
Simplex
Configuration Ports :
Monitor, Express port (customer choice)
MTBF :
ca. 500 years
Installation :
Simple to install, requires no configuration or maintenance
Usage :
Use with another 4 channels 1RU Rack Mount box, Duplex Dual Fiber Transmission, CWDM Mux and Demux in pair
Description

Optimized for Remote Connectivity 4 Channels 1RU Rack Mount Simplex BIDI CWDM Mux Demux for Edge and Remote Networks

Our 4-channel CWDM MUX DEMUX supports 4 different business channels.
It handles applications like 1G/10G Ethernet, SDH/SONET, and 8/4/2/1G over two optical fibers for efficient point-to-point transmission.
With this device, you’re always ready to tackle the demands of your industry.

Simplex CWDM MUX and DEMUX
Multiplexer (MUX) and demultiplexer (DEMUX) are combined together into a single piece of equipment for bi-directional data transmission over one fiber.
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Simplex Bi-Directional Transmission should be used in pairs, MUX/DEMUX Portfor specific wavelength must be opposite CWDM
HJY CWDM Mux/Demux is a passive technology, it allows for any protocol to be transported over the link, as long as it is at a specific wavelength (i.e. T1 over fiber at 1570nm transported alongside 10Gbps Ethernet at 1590nm). This allows for long-term future proofing of the networking infrastructure because the multiplexers simply refract light at any network speed, regardless of the protocol being deployed.

HJY provides a complete portfolio of CWDM Mux Demux and Optical Add Drop Multiplexer (OADM) units to suit all applications such as: Gigabit & 10G Ethernet, SDH/SONET, ATM, ESCON, Fibre Channel, FTTx and CATV. And we provide optional port configurations such as: Express Port, Monitor Port, 1310nm passband port and 1550nm port for these multiplexers according to customer choice.
Maximize Your Fiber with WDM Network
A single fiber can be shared for multiple different data or services in WDM network. It maximizes the usefulness of fiber and generates substantial savings.
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Mix of Services Multiplexing at Any Rate
Flexible mix of 1G/10G/25G/40G/100G/200G Ethernet, 8G/16G FC, SAN, OTN, SDH/SONET and native video services, it's transparent to any rate, any service multiplexing and upgrade
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Product Specification
Wavelength
1270-1610nm
Channel Spacing
20nm
Channel Passband
±6.5nm
Technology
TFF (Thin Film Filter)
Insertion Loss
Regular :≤ 5.4dB (With 8 Skip 0:≤3.0dB)
Link Loss(A+B)
Regular :≤ 6.2dB (With 8 Skip 0:≤4.0dB)
Center Wavelength Accuracy
±0.05nm
Return Loss
≥ 45dB
Directivity
≥ 45dB
Polarization Mode Dispersion
≤ 0.1ps
Polarization Dependent Loss
≤ 0.3dB
Channel Isolation
Adjacent ≥30dB Non-adjacent ≥45dB
Connector
LC/UPC
Temperature
Operating -40 to 85°C Storage -40 to 85°C
Net Weight
1U 19ich Chassis 1.2KG
Dimensions (HxWxD)
1u Rack 44*440*230mm
Note: Specified with connectors.
Mechanical Details for Housing
Remote Connectivity Passive Cwdm 4 Channels 1ru Rack Mount Cwdm Mux Demux For Networks
Note: Please, note that the drawings shown here only show the dimensions and do not the specific configuration of the module.
