3.7m/12ft High XPD Performance Dual Polarized Microwave Parabolic Antenna 48dbi
3.7m/12ft High XPD Performance Dual Polarized Microwave Parabolic Antenna 48dbi
Specifications
Payment Terms :
T/T ， L/C
Place of Origin :
China
Brand Name :
Famous
Certification :
CE，ISO9001
Model Number :
XPD Antenna
MOQ :
1 SET
Price :
Negotiable
Packaging Details :
Standard export packaging/customizable packaging
Diameter of Mounting Pole :
φ114 mm
Fine Azimuth Adjustment :
Coarse 360°Fine±5°
Fine Elevation Adjustment :
Fine±5°
Wind Velocity Operational :
180km/h
Wind Velocity Survival :
200km/h
Ice-load :
25.4 mm
Operational Temperature :
-55~+70℃
Description

3.7m/12ft High XPD Performance Dual-Polarized Microwave Parabolic Antenna

- Our patent split-lobe microwave communication parabolic antenna for large diameter, which can save packaging and transportation costs greatly without any quality compromised；

- High performance ultra high XPD parabolic antennas – Excellent performance for a wide range of applications；

- Simple Assembly – Minimal required assembly simplifies installation on site and guarantees “factory-tested” quality；

Electrical performance:

Antenna Model

Antenne

Size(m/ft)

Frequency (GHz)

Gain(dBi)

3dB BW (degs)

XPD

(dB)

VSWR

F/B radio (dB)

ISO

LoWMidTop

CMP373DB

3.7m/12ft

3.6-4.2

40.1

40.9

41.4

1.6

33

1.15

66

38

CMP374DB

3.7m/12ft

4.4-5.0

41.6

42.2

42.7

1.2

33

1.15

67

38

CMP376WDB

3.7m/12ft

5.925-7.125

44.4

45.2

46.0

1

33

1.1

71

38

CMP377WDB

3.7m/12ft

7.125-8.5

46.0

46.8

47.5

0.8

33

1.1

73

38

CMP3710WDB

3.7m/12ft

10-11.7

48.4

49.4

50.3

0.6

33

1.1

75

38

Mechanical performance:

Diameter of Mounting Pole

Φ114 mm

Fine Azimuth Adjustment

Coarse 360° Fine ±5°

Fine Elevation Adjustment

Fine ±5°

Wind Velocity Operational

180km/h

Wind Velocity Survival

200km/h

Ice-load

25.4 mm

Operational Temperature

-55~ +70℃

1.The low/mid/high gain has≤-0.5dBi tolerance is within the normal range;
2.F/Bradio:Denotes highest radiation relative to the main beam,at 180°±40°,across the band.Production antennas do not exceed rated values by more than 2 dB unless stated otherwise;
