Wideband 6 GHz Asymmetrical 90° Horn Antenna
Wideband 6 GHz Asymmetrical 90° Horn Antenna
Wideband 6 GHz Asymmetrical 90° Horn Antenna
Wideband 6 GHz Asymmetrical 90° Horn Antenna
Wideband 6 GHz Asymmetrical 90° Horn Antenna
Wideband 6 GHz Asymmetrical 90° Horn Antenna
Specifications
Brand Name :
Famous
Model Number :
Horn Antenna
Certification :
CE，ISO9001
Place of Origin :
China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T ， L/C
Packaging Details :
Standard export packaging/customizable packaging
Name :
Symmetrical Horn Antenna
Frequency Range :
4900-7200 MHz
Gain :
18 dBi
Azimuth Beam Width :
90°
Elevation Beam Width :
25°
Front-to-Back Ratio :
40 dB
Isolation :
>30 dB
VSWR Max :
1.6
Connector :
RP-SMA male pigtails
Description

Wideband 6 GHz Asymmetrical 90° Horn Antenna

Name: Symmetrical Horn Antenna Frequency Range: 4900-7200 MHz
Gain: 18 DBi Azimuth Beam Width: 90°
Elevation Beam Width: 25° Front-to-Back Ratio: 40 DB
Isolation: >30 DB VSWR Max: 1.6
Connector: RP-SMA Male Pigtails

Wideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn AntennaWideband 6 GHz Asymmetrical 90° Horn Antenna
