Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food
Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food
Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food
Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food
Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food
Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food
Specifications
Model Number :
NBCS-580
Price :
USD2741-USD3225/set
Place of Origin :
China
Brand Name :
NANBEI
Certification :
CE,ISO
MOQ :
1set
Delivery Time :
7-10days
Payment Terms :
TT, LC, Paypal, Western Union, MoneyGram…
Type :
NBCS-580
Size of integrating sphere :
Φ40mm, diffused reflection surface coating
Sensor :
dual light path sensor array
Wavelength Range :
400-700nm
Wavelength Interval :
10nm
Half spectral width :
5nm
Description

Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food

Brief introduction of Portable Spectrophotometer:

Our device adopts internationally agreed observe condition D/8 (Diffused lighting, 8 degrees observe angle) and SCI(specular reflection included)/SCE(specular reflection excluded). It could be used for color matching for many industries and widely used in painting industry, textile industry, plastic industry, food industry, building material industry and other industries for quality control.

Features of Portable Spectrophotometer:

1. Camera view to catch the testing area

2. Uses CLEDs light source – spectrally balanced LED light source

3. Our spectrophotometer comes with the color QC software, which is applicable in various industries’ quality control and management of color data

4. Automatic gloss compensation technology.

5. Free Color Management Software

6. Innovative light splitting SCS optical engine

7. The device could store 100 standard sample groups and every sample group could store 100 sample data.

8. The most complete and color indicators compares with similar instruments.

9. Longest Device Guarantee Time

Portable Chemical Analysis Equipment Spectrophotometer For Painting Textile Plastic Food

Type NBCS-580
Illumination d/8(Diffused lighting, 8 degrees observe angle),SCI(specular reflection included)/SCE(specular reflection excluded)simultaneous measurement.(conform to CIE No.15,ISO 7724/1,ASTM E1164,DIN 5033 Teil7, JIS Z8722 Condition c standards)
Size of integrating sphere Φ40mm, diffused reflection surface coating
Illumination Light source CLEDs(entire wavelength balanced LED light source)
Sensor dual light path sensor array
Wavelength Range 400-700nm
Wavelength Interval 10nm
Half spectral width 5nm
Reflectivity range 0-200%
Reflectivity resolution 0.01%
Observation angle 2°/10°
Measurement light source A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,DLF,TL83,TL84,NBF,U30,CWF
Data being displayed SPD distribution/data,sample's color values,color difference values/graph,pass/fail results,color error tendency,color simulation,display measurement area,history data color simulation,manual input standard sample,generate measurement report
Measurement time interval 2 seconds
Measurement time 1 second
Color space CIE-L*a*b, L*C*h, L*u*v, XYZ, Yxy, Reflectance
Color difference formulas ΔE*ab, ΔE*CH, ΔE*uv, ΔE*cmc(2:1), ΔE*cmc(1:1),ΔE*94,ΔE*00
Other colorimetric indices

WI(ASTM E313-10,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger, Ganz, Stensby)； YI(ASTM D1925,ASTM E313-00,ASTM E313-73)；Tint(ASTM E313,CIE,Ganz)

Metamerism index Milm, Stick color fastness, Color fastness
Repeatability light splitting reflectivity:standard deviation within 0.08%

color values:ΔE*ab<=0.03(After calibration, standard deviation of 30 measurements on test white board, 5 second intervals),

Maximum:0.05
Battery capacity rechargeable, 10000 continuous tests, 7.4V/6000mAh
Interface USB
Data storage 20000 test results
Light source longevity 5 years, 1.5 million tests
Inter-instrument agreement ΔE*ab within 0.2(BCRA color charts II, average of the 12 charts)
Size 181*73*112mm(L*W*H)
Weight about 550g(does not include battery's weight)
Display True color screen that includes all colors
Work temperature range 0~45℃, relative humidity 80% or below( at 35°C ),no condensation
Storage temperature range -25℃ to 55℃,relative humidity 80% or below(at 35°C ),no condensation
Standard accessories DC adapter, Lithium battery, manual, color management software, drive software, electronic manual, color management guide, USB cable, black/white calibration tube, protective cover, spire lamella, portable bag, electronic color charts
Optional accessories powder molding device, micro printer, measurement and test report
Color matching system not match
UV light source without UV light source
