Full Automatic 12 Bags / Pack Facial Tissue Packing Machine
Full Automatic 12 Bags / Pack Facial Tissue Packing Machine
Full Automatic 12 Bags / Pack Facial Tissue Packing Machine
Full Automatic 12 Bags / Pack Facial Tissue Packing Machine
Specifications
Brand Name :
ACE
Model Number :
ACE-FBM-A
Certification :
CE
Place of Origin :
CHINA
MOQ :
1set
Price :
$20000 - 60000/set
Payment Terms :
L/C, , T/T
Supply Ability :
10 set /month
Delivery Time :
60 days
Packaging Details :
standard export packing
other name :
Full Automatic facial tissue Multi Packs Bundling Machine
Control :
Servo and PLC control
Date setting :
Toucn screen
Pack speed :
25 bundle / minute
After-sales service provided :
Engineers available to service machinery overseas
Working products :
facial tissue and napkins
Description

Full Automatic facial tissue Multi Packs Bundling Machine 12 bag/pack

Application of this Full Automatic facial tissue Multi Packs Bundling Machine 12 bag/pack:

This Full Automatic facial tissue Multi Packs Bundling Machine 12 bag/pack is suitable for automatic bundling bag packaging of single film packed removable facial tissue,hand towel and napkin.

The tissue arangment,flip,counting line up,bag push,forward filling,bag filling,pulling,sending,opening.sealing,cutting and other actions implementing organization all use servo drive control,simple operation and easy maintenance.

Configure bag opening detection ptotection,waste bag automatic stop-out,air source management,self-diagnosis fault alarm display,servo overload protection and incoming automatic distribution function.

Single lane in a bag and double lanes in a bag interchangeability,simple specification oversion,easy operation and high efficiency.

Main features:

1. adopt PLC and servo motors to drive the products feeding, overturn, counting, bag feeding, bag opening, bagging, sealing automatically.

2. bagging and sealing: adopt the mound negative pressure type bagging and sealing to keep the products shape nicely.

3. Fault tracked and warmed: the fault will be showed on the touch screen and tracked the reason to make easy to solve the fault.

4. monitoring system: bags controlled, product checking to keep the machine won’t pack without products;and the checking system help to output the defective goods. In case that the bag can not open, machine will automatic stop. In case the bag is fault and cannot open, the bag will output automatically.

Technical parameter of Automatic facial tissue bundle packing machine PLC high speed 25 bundle / min

Machine model ACE-FBM-A
Packing speed 10-25packs/min
Max bundle bag length 420mm
Finished bundle bag width 130-420mm
Finished bundle bag height 90～105mm
Bundle bag max length 640mm
Bundle bag packing type 3,4,5,6,8,10bags/bundle
Bundle bag material Pre-made M bag with air outlet hole(dia 5-6mm),the thickness is 40-60μm, opp, cpp, pe double side sealing film
Pre-made bag qty 2 bag base for changing and each one can hold 300-400 pcs
Machine out-dimension 4900×2900×1920 mm
Machine power supply 380V±10%,50Hz±5%
Air supply 0.6～0.7Mpa ,330L/min
Machine weight About 2500kg
Noise <80dB
Total power 12.56Kw

Sample of finished product by fully Full Automatic facial tissue Multi Packs Bundling Machine 12 bag/pack.
