Napkin Making Machine With High Quality Four Colors Printing
Napkin Making Machine With High Quality Four Colors Printing
Napkin Making Machine With High Quality Four Colors Printing
Napkin Making Machine With High Quality Four Colors Printing
Specifications
Brand Name :
ACE
Model Number :
ACE-TNM-4C
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10 set /month
Delivery Time :
60 days
Packaging Details :
standard export packing
Name :
Napkin Making Machine With Printing
Speed :
200m/min
Napkin size :
300x300mm or multi sizes.
Folding style :
1/4 type
color register tolerance :
±0.1mm.
Printing :
four colors high quality
Description

Napkin Paper Machine With Two Colors Printing Tolerance ± 0.1mm

Application

This ACE-TNM-4C Napkin Making Machine With High Quality Four Colors Printing is mainly used for production of high quality four color printing on napkins. It is with high resolution and color register tolerance ± 0.1mm. It can automatically fold, emboss, print, cut and count 1/4 fold table napkins, cocktail napkin, restaurant napkins, beverage napkin, lunchen napkin, 1/6 fold tallfold dispenser napkin, wallet tissue and MG paper napkins etc. The mainly function of this machine is to make multi colors printed high resolution high quality printing of four colors printing up to eight colors. This napkin making machine with four colors printing can be also print up to 8 colors or point to point lamination.

Advantage:

1 Best napkin making machine with four colors.

2 High resolution printing machine.

3 With four colors printing.

4 With auto web tension system

5 With auto edge guiding system

6- Color register tolerance: ±0.1mm.

7- napkin making machine manufacturer since 1992.


Technical parameters as below

Italy Design Automatic High Speed Four Colors Printing Paper Napkin Machine

Model ACE-TNM-4C the best quality napkin making machine with four colors printing
Output type single lane
Folding speed

200 m/min, about 400-700 piece/min, depending on the paper quality and napkin size.
Raw paper

13-20g/m2 2-ply, 20-45g/m2 1-ply, wooden pulp paper or others.

Other sizes please specify.
Jumbo roll size ≤ (200-460)mm x Φ1200mm (Depending on your napkin size,customized)
Napkin unfolded size 200mm x 200mm to 460mm x 460mm or Customized.
Napkin folded size

100mm x 100mm to 230mm x 230mm

One size is fixed.

One napkin size is adjustable, decided by the paper roll width.
Folding type

Mechanical fold with band saw cutting; 1/4 fold;

Vacuum folding and other folding types available.
Printing unit

1- Flexo printing type.

2- Printing colors customized up to four colors printing.

Color register tolerance: ± 0.1mm.

3- Printing Logo is changeable. You just need to change the Printing Rubber only.

4- With ceramix Anilox roll to transfer the inks.

5- Printing roll is adjustable.

6- Ink printing system to be negotiated.
Tension control

Speedless Tension control unit to fit the machine for paper of different quaity and different gsm.

With automatic web guiding system.

With automatic web tension control system.
Power 10Kw depends on requiremetns (3-phase AC380V 50Hz or customized)
Machine size 7x2x3m
Weight 4000KG
Videos and photos available.

B. Feeding Section

1. With 1 unwind stands;

2. Floor-standing thickened Wallboard structure (complete steel plate) to ensure high speed stable running no vibration.

3. Pneumatic cylinder control

4. Stepless adjusting speed to control web-tension of paper.

5. Auto adjustment setting

6. With pneumatic system to automatically load jumbo rolls.

7. With automatic web tension control system. Web tension control: constant tension control by floating roll.

8. With automatic edge guiding system. Automatic electrical deviation control: Internationally famous brand.

9. Paper transport: step-less speed regulating (triangular belt).

B. Feeding Section

1. With 1 unwind stands;

2. Floor-standing thickened Wallboard structure (complete steel plate) to ensure high speed stable running no vibration.

3. Pneumatic cylinder control

4. Stepless adjusting speed to control web-tension of paper.

5. Auto adjustment setting

6. With pneumatic system to automatically load jumbo rolls.

7. With automatic web tension control system. Web tension control: constant tension control by floating roll.

8. With automatic edge guiding system. Automatic electrical deviation control: Internationally famous brand.

9. Paper transport: step-less speed regulating (triangular belt).

C. Embossing Section

1. One set of steel to paper embossing unit. (Embossing pattern provided by client or recommend by us)

2. Mechanical press type.

3. Floor-standing thickened Wallboard structure(complete steel plate) to ensure high speed stable running no vibration.

4. With 1 set of steel to steel Calendering unit.

F. Control system

1. With JOG function.

2. With emergency stop function.

3. With auto sensors for detecting paper breaks or used up. Machine will automatically stop if paper breaks or used up.

4. Famous brand motor and bearings.

5. Installed Power: total about 11.7 kw (3-phase AC380V 50Hz or customized)

-Main motor power: 4.5kw

-Band saw: 2.2KW

-Heating dryer: 2KW

-Lighting: 1KW

-Others: 2KW

6. Pressure: 0.5MPa.

7. Machine size about ( L*W*H) 6050*1530*2500mm

8. Weight: about 4000 kg

Configuration:

Bearings NSK
PLC Siemens
Inverter Siemens
Touch screen Siemens
Auto web guide Italy Best
Auto tension system Like
Steel High Speed steel
Anilox Ceramix

Products made by this Napkin Making Machine With High Quality Four Colors Printing for reference.:
