Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Specifications
Model NO. :
PZ12V190B
Number of Strokes :
Four-Stroke
Cylinder Arrangement Form :
V
Number of Cylinders :
12-Cylinder
Type :
Combustion Engine
Transport Package :
Wooden Cases
Specification :
1000
Trademark :
jichai
Origin :
China
HS Code :
8409999000
Supply Ability :
50000pecises/Year
Ignition Mode :
Ignition
Speed :
High Speed
Cooling Cylinder :
Water-Cooled
Intake Pressure Impulse :
Naturally Aspirated
Piston Movement :
Reciprocating
Fuel :
Diesel
Customization :
Available | Customized Request
Place of Origin :
china
Certification :
ISO9001
MOQ :
1
Price :
10-1000
Packaging Details :
Wooden box and carton packaging
Delivery Time :
15 days
Payment Terms :
TT,western
Description
Jichai Power Generating Set Pz12V190b Exhaust Manifold Assembly with Customized Request
Model Z12V190B diesel engines
Model Rated Power(KW/hp) Rated Speed(r/min) Specific fuel consumption(g/kw.h) Specific oil consumption(g/kw.h) Overall Dimension L*B*H(mm) Net weigh(KG)
Z12V190B 882/1500 794/1500 ≤209.4 ≤1.6 2692*1560*2070 5300
PZ12V190B 882/1500 794/1500 ≤209.4 ≤1.6 4301*1980*2678 7500
Z12V190B-3 820/1300 738/1300 ≤209.4 ≤1.6 2692*1560*2070 5300
PZ12V190B-3 820/1300 738/1300 ≤209.4 ≤1.6 4301*1980*2678 7500
Z12V190B-1 735/1200 662/1200 ≤209.4 ≤1.6 2692*1560*2070 5300
PZ12V190B-1 735/1200 662/1200 ≤209.4 ≤1.6 4301*1980*2678 7500
Z12V190B-2 588/1000 529/1000 ≤209.4 ≤1.6 2692*1560*2070 5300
PZ12V190B-2 588/1000 529/1000 ≤209.4 ≤1.6 4301*1980*2678 7500
Z8V190 588/1500 529/1500 ≤213.5 ≤2.7 2112*1560*2080 4300
PZ8V190 588/1500 529/1500 ≤213.5 ≤2.7 3950*1980*2678 6750
Z8V190-1 471/1200 425/1200 ≤213.5 ≤2.7 2112*1560*2080 4300
PZ8V190-1 471/1200 425/1200 ≤213.5 ≤2.7 3950*1980*2678 6750
Z8V190-2 390/1000 350/1000 ≤213.5 ≤2.7 2112*1560*2080 4300
PZ8V190-2 390/1000 350/1000 ≤213.5 ≤2.7 3950*1980*2678 6750
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
series 2000 diesel engines
Model Rated Power(KW/hp) Rated Speed(r/min) Specific fuel consumption(g/kw.h) Specific oil consumption(g/kw.h) Overall Dimension L*B*H(mm) Net weigh(KG)
BG12V190ZL 900/1500 800/1500 ≤209.4 ≤1.6 3160*1770*2400 5300
BG12V190PZL 900/1500 800/1500 ≤209.4 ≤1.6 4374*1740*2400 8100
BG12V190ZL-3 810/1300 730/1300 ≤209.4 ≤1.6 3160*1770*2400 5300
BG12V190PZL-3 810/1300 730/1300 ≤209.4 ≤1.6 4374*1740*2400 8100
G12V190ZL 900/1500 800/1500 ≤209.4 ≤1.6 2692*1560*2070 5300
G12V190PZL 900/1500 800/1500 ≤209.4 ≤1.6 3860*2040*2678 8100
G12V190ZL-3 810/1300 730/1300 ≤209.4 ≤1.6 2692*1560*2070 5300
G12V190PZL-3 810/1300 730/1300 ≤209.4 ≤1.6 3860*2040*2678 8100
G12V190ZL-1 740/1200 660/1200 ≤209.4 ≤1.6 2692*1560*2070 5300
G12V190PZL-1 740/1200 660/1200 ≤209.4 ≤1.6 3860*2040*2678 8100
G12V190ZL-2 600/1000 540/1000 ≤209.4 ≤1.6 2692*1560*2070 5300
G12V190PZL-2 600/1000 540/1000 ≤209.4 ≤1.6 3860*2040*2678 8100
G8V190ZL 600/1500 540/1500 ≤213.5 ≤2.7 1802*1560*2070 4300
G8V190PZL 600/1500 540/1500 ≤213.5 ≤2.7 3280*2040*2678 6750
G8V190ZL-3 510/1300 460/1300 ≤213.5 ≤2.7 1802*1560*2070 4300
G8V190PZL-3 510/1300 460/1300 ≤213.5 ≤2.7 3280*2040*2678 6750
G8V190ZL-1 470/1200 425/1200 ≤213.5 ≤2.7 1802*1560*2070 4300
G8V190PZL-1 470/1200 425/1200 ≤213.5 ≤2.7 3280*2040*2678 6750
G8V190ZL-2 390/1000 350/1000 ≤213.5 ≤2.7 1802*1560*2070 4300
G8V190PZL-2 390/1000 350/1000 ≤213.5 ≤2.7 3280*2040*2678 6750
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45(47.6)L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
