High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
Specifications
Model NO. :
CO1300F-3/25
Number of Strokes :
Four-Stroke
Cylinder Arrangement Form :
V
Number of Cylinders :
12-Cylinder
Type :
Combustion Engine
Transport Package :
Wooden Cases
Specification :
9300KG
Trademark :
Jichai chidong
Origin :
China
HS Code :
8408201090
Supply Ability :
50000pecises/Year
Ignition Mode :
Ignition
Speed :
High Speed
Cooling Cylinder :
Water-Cooled
Intake Pressure Impulse :
Supercharged
Piston Movement :
Reciprocating
Fuel :
Diesel
Customization :
Available | Customized Request
Place of Origin :
china
Certification :
ISO9001
MOQ :
1
Price :
10-1000
Packaging Details :
Wooden box and carton packaging
Delivery Time :
15 days
Payment Terms :
TT,western
Description

High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
series 3000 long stroke diesel engines
Model Rated Power(KW/hp) Rated Speed(r/min) Specific fuel consumption(g/kw.h) Specific oil consumption(g/kw.h) Overall Dimension L*B*H(mm) Net weigh(KG)
L12V190ZL-1 1200/1200 1080/1200 ≤202 ≤1.0 2950*1980*2312 9300
L12V190PZL-1 1200/1200 1080/1200 ≤202 ≤1.0 3980*2250*2850 11000
L12V190ZL-2 1000/1000 900/1000 ≤202 ≤1.0 2950*1980*2312 9300
L12V190PZL-2 1000/1000 900/1000 ≤202 ≤1.0 3980*2250*2850 11000
L12V190ZL-3 1300/1300 1170/1300 ≤202 ≤1.0 2950*1980*2312 9300
L12V190PZL-3 1300/1300 1170/1300 ≤202 ≤1.0 3980*2250*2850 11000
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:255mm
Total displacement:86.72L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
Main specification of diesel coupling sets
Model of coupling sets Power(KW)/Speed(r/min) Model of diesel engine Model of Coupling Reduction ration Overall Dimension L*B*H(mm) Centre height(mm
)
CO1300F-3/25 1300/1300 L12V190PZL-3 YOTFJ875-25FLsh 2.5 6410*2335*2740 1355
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
High Speed 12-Cylinder L12V190zl Co1300f-3/25 Jinan Jichai Diesel Engine for Industrial
